Haiyang Smart7 - AIS Information Windows and Tracking

- 35 -
Target
to red color.
Sleeping
Target
Target located outside the Activation Range. Sleeping target is represented by a
small oriented triangle.
Lost Target
When the AIS info is not received from that vessel. The presentation will be
marked X on the target.
3. AIS information window
Press [ENTER] key on Target which wants to see. It shows Information of “AIS INFO” window.
(Fig.2.1)
