C. Soldering station
1. Insert the power cord into the receptacle at
the back of the station.
Insert the soldering iron cord into the
receptacle at the front of the station.
2. Set the iron in the iron holder .
3. Plug the power cord into a grounded wall
socket. The Hakko 942 is protected against
electrostatic discharge and must be
grounded for full efficiency.
To remove the cord,
draw the plug from
the receptacle while
pressing the release pin.
Receptacle
When the plug ‘clicks’,
it is fully inserted.
CAUTION:
Be sure the power switch is OFF before connecting or
disconnecting the soldering iron cord. Failure to do so
may result in damage to the circuit board.
5
