8. FOOTSWITCH Connection: This pneumatic barb connects to the hose of the pneumatic footswitch. Like the OUTPUT ON/OFF switch, the FOOTSWITCH controls
stimulus output in the STIMULATION modes and controls RF output in the LESION, COOLED RF, TRANSDISCAL, RFA and IDL modes. The action of the FOOTSWITCH
diers from the OUTPUT ON/OFF switch: the FOOTSWITCH must be held down to continue delivery of stimulus pulses or RF energy.
9. RS-232 Connection: This is an isolated connection to a standard 9-pin COM port. It is provided for passive data acquisition, and cannot be used to control the
system.
10. RJ45 Connector: Connection to be used by authorized service personnel only.
11. Pump Module Interface Connector: For attachment of authorized cooling pump unit only.
6 Factory Set Defaults
Factory Set Defaults
Mode Settings Adjustment Range “Factory Set” Value
VOLTAGE
STIMULATION
STIM RATE 1-Shot, 2, 5, 10, 20, 50, 75, 100, 150, 180, 200 Hz 2 Hz
PULSE DUR 0.1, 0.2, 0.5, 1.0 ms 1.0 ms
VOLTAGE 0.0 –10.0 V 0.0 V
CURRENT
STIMULATION
STIM RATE 1-Shot, 2, 5, 10, 20, 50, 75, 100, 150, 180, 200 Hz 2 Hz
PULSE DUR 0.1, 0.2, 0.5, 1.0 ms 1.0 ms
CURRENT 0.0 –10.0 mA 0.0 mA
AUTO TEMP LESION
SET TEMP 38° – 95°C 80°C
TIME 15 – 600 s 75 s
MULTI-RF (TRUE-TX) MAX RAMP TIME EXTENSION DISABLE, 5–120 s, with 5 s interval 30 s
MANUAL POWER
LESION
TEMP LIMIT 38° – 95°C 80°C
TIME 15 – 600 s 75 s
SET POWER 0 – 50 W 0 W
AUTO PULSED
LESION
SET TEMP 38° – 95°C 42°C
TIME 10 – 900 s 120 s
PULSE DUR 10 – 100 ms, with 10 ms interval 20 ms
PULSE RATE 1 – 10 Hz 2 Hz
MANUAL PULSED
LESION
WARNING TEMP 38° – 95°C 42°C
TIME 10 – 900 s 120 s
PULSE DUR 10 – 100 ms, with 10 ms interval 20 ms
PULSE RATE 1 – 10 Hz 2 Hz
COOLED RF
SET TEMP 30° – 90°C 60°C
TIME 15 s–30 min 2 min 30 sec
MULTI-COOLED RF
MAX RAMP TIME EXTENSION DISABLE, 5–180 s, with 5 s interval 60 s
SET TEMP 38° – 95°C 60°C
IMPEDANCE CUTOFF MULTIPLIER DISABLE, 2.0 – 4.0, with 0.1 interval 2.0
TIME (1 Probe) 15 s – 30 min with 15 s interval 2 min 30 sec
TIME (2 Probes) 15 s – 30 min with 15 s interval 2 min 30 sec
TIME (3 – 4 Probes) 15 s – 30 min with 15 s interval 2 min 45 sec
TRANSDISCAL
SET TEMP 30° – 90°C
BIPOLAR 50°C
MONOPOLAR 60°C
TIME 1 – 30 min
BIPOLAR 15 min
MONOPOLAR 2 min 30 sec
RFA
SET TEMP 38° – 95°C 55°C
TIME 1 – 30 min 10 min
IDL
SET TEMP 40° – 95°C 90°C
TIME 30 s – 20 min 16 min 30 sec
