Planer-Thicknesser
A3-26 / A3-31 / A3-41
4 Technical specifications
Fig. 4-1: Dimensions
*
)
The transport width measures under 800 mm. This makes it possible to transport the machine through doorways.
4.1 Dimensions and weight
4.2 Electrical connection
Machine A3-26 A3-31 A3-41
Total length (A) 1255 mm 1535 mm 1933 mm
Overall width (B) 740 mm 790 mm 890 mm
Working height - Planer tables (C) 850 mm 850 mm 850 mm
Total planer table length (D) 1120 mm 1400 mm 1800 mm
Surface planing width (E) 260 mm 310 mm 410 mm
Weight 195 kg 240 kg 295 kg
Machine including packaging A3-26 A3-31 A3-41
Length 1160 mm 1410 mm 1810 mm
Width
*
)
540 mm 580 mm 770 mm
Height 1090 mm 1090 mm 1090 mm
Weight 255 kg 300 kg 355 kg
Mains voltage 230/400 ±10% V
Safeguarding 16 A
triggering characteristic C
Technical specifications
