Hammer A3-26 User Manual

18
!
"
)
#
$
%
&
/
(
Planer-Thicknesser
A3-26 / A3-31 / A3-41
5 Assembly
5.1 Overview
Fig. 5-1: Overview
! Housing with drive motor and gearbox
" Thicknesser unit
# Vacuum hood with vacuum connector
$ Bridge guard
% Planer table, receiver-side
& Combination fence (with rear cover for the cutter-
block)
/ Planer table, feeder-side
( Cutterblock with thread for mortising chuck
) Switching point
Assembly
