Hammer N3700 e-classic - 4 Specifications; Dimensions and Weight; Noise Emission

12
L
B
H
Bandsaw
N3700 e-classic / N3800 / N4400
4 Specifications
4.1 Dimensions and weight
4.2 Noise emission
The given values are emission values and not safe work-
place values. Although there is a correlation between
emission and immission levels, it is not possible to state
whether increased safety measures are required.
Factors which can considerably influence the present
immission level at the workplace include the duration of
exposure, the character of the work area and other influ-
ences in the neighbouring area.
Acceptable workplace values may also vary from coun-
try to country. However, this information should help the
user to better assess the hazards and risks.
Depending on the installation location and other
variables, the resulting noise emission can differ by up
to 4 db (A) from the given values.
Fig. 4-1: Total size
Specifications
Bandsaw N3700/N3800 N4400
Cutting height 310 mm 310 mm
Rip capacity max. 360 mm 420 mm
- || - Rip fence 320 mm 377 mm
Saw blade length 3556 mm 3976 mm
Saw blade width 6 - 20 mm 6 - 25 mm
Saw blade speed 20 m/sec 20 m/sec
Wheel diameter 380 mm 440 mm
Table size 400 x 510 mm 420 x 575 mm
Tiltable table -5° max. +45° -10° max. +45°
Machine (L x W x H) N3700/N3800 N4400
Total size 829 x 800 x
454 x 650 x
1750 mm 1865 mm
Package size 640 x 780 x
390 x 660 x
1820 mm 1900 mm
Net weight 150 kg 170 kg
Model L Aeq LW (A) Lpc
N3800 84,5 dB (A) 93,7 dB (A) 2,3 mW < 130 dB (A)
N4400 84,7 dB (A) 97,1 dB (A) 5,1 mW < 130 dB (A)
