Hammond B-3 User Manual

Hook-Up
31
USING TWO LESLIE SPEAKERS
Two Leslie Speakers may be connected to this organ.
Connect the first Leslie Speaker to the MAIN socket and the sec-
ond to the ECHO socket. The organ sounds are usually produced
from both Leslie Speakers. If you connect the MAIN/ECHO
switch, you can select which Leslie sounds while you are play-
ing.
The sound that is input from LINE IN jack will be sent out to
both Leslie speakers regardless of the position of the MAIN/ECHO
switch.
REINFORCING THE BASS
To reinforce the bass, or if you do not wish to have the Pedals
speak through the Leslie, you can send the Pedal part directly to
a bass amp or PA system using the independent PEDAL OUT
jack. Set your PEDAL OUT preference by the OUTPUT param-
eter of the OUTPUT on the PEDAL PART page in the SYSTEM
function mode. (P. 96 #1)

Hammond B-3 Specifications

General

Type	Tonewheel Organ
Manufacturer	Hammond Organ Company
Introduced	1954
Manuals	2
Keys per Manual	61
Pedalboard	25-note
Vibrato/Chorus	Yes
Percussion	Yes
Drawbars	9 per manual
Tone Generation	Tonewheel
Reverb	No (typically added externally)
Amplification	External
Weight	425 lbs
