105
MIDI
P
ANIC FUNCTION and P
ARAMETER RELOAD
If any problem happens in the MIDI system, it may cause ciphering (sticking notes). Immediately after
this organ and an external MIDI equipment are connected, a glitch or “MIDI hangup” may occur
.
If this occurs, press P
AGE [
S
] and [
T
] at the same time. [All Note Off] and [Reset All Controller]
will be transmitted to all External Zone MIDI channels (Panic Function) and then all the EXTERNAL
ZONE settings will be re-sent.
