*#1 $OM%OM$2OMOwner’s Manual
16
Connect the Expression Pedal
Insert the plug the cable from the Expression Pedal to the
EXP.PEDAL connector on the power panel (on the bot-
tom of the organ), matching the direction, then tighten it
by turning the ring on it.
Connect the Pedalboard
(optional)
1. Insert the cable of the Pedalboard PK-25PR to the con-
nector of the Pedalboard and the PEDALBOARD con-
nector on the power panel (on the bottom of the organ),
matching the direction, and secure it by turning the ring
on the plug clockwise.
2. Insert the plug of the cable from the Expression Pedal to
the EXP.PEDAL connector on the power panel (on the
bottom of the organ), matching the direction, then fix it
by turning the ring on the plug clockwise.
