2.3 Compressor specifications
Model RTM-090
Refrigerant R134a
Nominal cooling capacity USRT 400~450
Compressor
Type Two-stage compression
Axial guide vane
control
IGV 20~100% continuous
Frequency Hz 225
Motor
Type 3 Phase, 2 Pole, Permanent magnet
Starting VFD
Voltage V 380~460±5%
Insulation Class H
Protection
PT100*6
Transmission
Type Direct-driven
Lubrication Oil free
Dimension (LxWxH) m 1.3 X 0.8 x 0.7
Weight kg 1050
Hydrostatic pressure test kg/cm²g 22
Refrigerant heater kW 1x 0.3
Table 2.1 Compressor specifications
RTM-090 Performance
USRT RPM COP IPLV
400 13,000 6.53 11.0
450 13,500 6.33 10.5
Table 2.2 Compressor performance
Note: The performance is based on AHRI condition assuming a discharge check valve is installed.
