24
Model
1000 1250 1500 1750 2000 2500 3000
Electrical Data
Nominal Voltage 230/3/60 **
Voltage Range 207 - 253
Input Power @ Rated Flow (watts) * 6,130 7,290 9,470 11,360 11,360 15,030 19,670
Minimum Circuit Ampacity 25 31 39 46 46 55 79
Maximum Overcurrent Protector (amps) 40 50 60 75 75 90 125
Compressor Rated Load Amps 8.6 10.7 12.9 15.7 15.7 19.3 25.7
Compressor Locked Rotor Amps 42 67 80 90 90 105 140
Compressor Winding Resistance (ohms) 3.80 2.41 1.90 1.85 1.85 1.57 1.10
Nominal Voltage 460/3/60
Voltage Range 414 - 506
Input Power @ Rated Flow (watts) * 6,130 7,290 9,470 11,360 11,360 15,030 19,670
Minimum Circuit Ampacity 13 15 20 23 23 28 39
Maximum Overcurrent Protector (amps) 20 25 30 35 35 45 60
Compressor Rated Load Amps 8.6 10.7 12.9 15.7 15.7 19.3 25.7
Compressor Locked Rotor Amps 42 67 80 90 90 105 140
Compressor Winding Resistance (ohms) 3.80 2.41 1.90 1.85 1.85 1.57 1.10
Nominal Voltage 575/3/60 **
Voltage Range 518 - 633
Input Power @ Rated Flow (watts) * 6,130 7,290 9,470 11,360 11,360 15,030 19,670
Minimum Circuit Ampacity 10 12 16 19 19 22 31
Maximum Overcurrent Protector (amps) 15 20 25 30 30 35 50
Compressor Rated Load Amps 8.6 10.7 12.9 15.7 15.7 19.3 25.7
Compressor Locked Rotor Amps 42 67 80 90 90 105 140
Compressor Winding Resistance (ohms) 3.80 2.41 1.90 1.85 1.85 1.57 1.10
Nominal Voltage 380-420/3/50
Voltage Range 342 - 462
Input Power @ Rated Flow (watts) * 4,180 4,970 6,450 7,740 7,740 10,240 13,410
Minimum Circuit Ampacity 13 15 20 23 23 28 39
Maximum Overcurrent Protector (amps) 20 25 30 35 35 45 60
Compressor Rated Load Amps 8.6 10.7 12.9 15.7 15.7 19.3 25.7
Compressor Locked Rotor Amps 42 67 80 90 90 105 140
Compressor Winding Resistance (ohms) 3.80 2.41 1.90 1.85 1.85 1.57 1.10
Notes
* 60 Hz: 35°F Evaporator & 100°F Ambient; 50 Hz: 35°F Evaporator & 77°F Ambient
** 230/3/60 and 575/3/60 units use equipment transformers on incoming power. Compressor and fan voltage is 460/3/60.
ENGINEERING DATA
