PARTS LIST
PARTS DESCRIPTION 1000 1250 1500 1750 2000 2500 3000
Refrigerant Type (see Serial Tag for charge amount)
R-404a R-404a R-404a R-404a R-404a R-404a R-404a
Compressor
3136250 3110640 5000012 3093647 3093647 3107110 5000420
Condenser Assembly - Air-Cooled (includes condenser and fans)
5000763 5000764 5000765 5000766 5000766 5000767 5000768
Contactor - Compressor
5002926 5002926 5002926 5002928 5002928 5002928 5003511
Contactor - Fan Motor
5002926 5002926 5002926 5002926 5002926 5002926 5002926
Auxiliary Contacts - Compressor - NC
3221413 3221413 3221413 3221413 3221413 3221413 3221413
Auxiliary Contacts - Compressor - NO
3221412 3221412 3221412 3221412 3221412 3221412 3221412
Control Board
3227156 3227156 3227156 3227156 3227156 3227156 3227156
Disconnect Switch
3246083 3246083 3246083 3246083 3246083 3246083 3246084
Fan Assembly (includes motor, blade and guard)
3243804 3243804 3243805 3243805 3243805 3243805 3243805
Filter/Dryer - Liquid Line
3223812 3223812 3223812 3243615 3243615 3243616 3243616
Fuse - Control Board
5002943 5002943 5002943 5002943 5002943 5002943 5002943
Fuse - Control Transformer - primary
3246089 3246089 3246089 3246089 3246089 3246089 3246089
Fuse - Control Transformer - secondary
3246090 3246090 3246090 3246090 3246090 3246090 3246090
Fuse - Crankcase Heater
3246089 3246089 3246089 3246089 3246089 3246089 3246089
Heater, Crankcase
3076779 3076779 3076779 3076779 3076779 3076779 3076779
Motor Starter Protector - Compressor
3246080 3246080 5003505 5003504 5003504 5003504 5006081
Motor Starter Protector - Fan
3246077 3246077 3246078 3246078 3246078 3246078 3246079
Relay - High Pressure Cut-out
3246088 3246088 3246088 3246088 3246088 3246088 3246088
Sensor - Air Temperature
3210927 3210927 3210927 3210927 3210927 3210927 3210927
Sensor - Evaporator Outlet Temperature
7428484 7428484 7428484 7428484 7428484 7428484 7428484
Strainer - Hot Gas Bypass Line
4006435 4006435 4006435 4006436 4006436 4006436 4006436
Switch - Fan Cut-out #1
3230765 3230765 3230765 3230765 3230765 3230765 3230765
Switch - Fan Cut-out #2
N/A N/A 3230766 3230766 3230766 3230766 3230766
Switch - High Pressure Cut-out (air-cooled units)
3230770 3230770 3230770 3230770 3230770 3230770 3230770
Switch - Low Pressure Cut-out
3230769 3230769 3230769 3230769 3230769 3230769 3230769
Switch - Digital Temperature
7428483 7428483 7428483 7428483 7428483 7428483 7428483
Transformer - Control
3246082 3246082 3246082 3246082 3246082 3246082 3246082
Valve - Automatic Drain (complete)
3232366 3232366 3232366 3232366 3232366 3232366 3232366
Valve - Hot Gas Bypass
3232527 3232527 3232527 3232548 3232548 3232548 3232548
Valve - Thermostatic Expansion (TXV)
3232550 3232550 3232550 3232532 3232532 3232533 3232533
Water-Cooled Units Only
Condenser - Water-Cooled
3223341 3223342 3223343 3223346 3223346 3223346 3223345
Replacement Screen - Water Strainer
3230673 3230662 3230662 3230664 3230664 3230664 3230664
Strainer - Water
4009635 4009636 4009636 4009637 4009637 4009637 4009637
Switch - High Pressure Cut-out (water-cooled units)
3230771 3230771 3230771 3230771 3230771 3230771 3230771
Valve - Water Regulating
4006391 4006392 4006392 4006393 4006393 4006393 4006393
230/3/60 Units Only
Main Transformer - 230/460
3230906 3230906 3230906 3230896 3230896 3230897 3230897
575/3/60 Units Only
Main Transformer - 575/460
3230907 3230895 3230895 3230908 3230908 3230908 3230908
Maintenance Kits
Moisture Separator Filter
(includes separator elements & drain rebuild kit)
HPRPMK27S HPRPMK27S HPRPMK27S HPRPMK28S HPRPMK28S HPRPMK28S HPRPMK28S
Optional Oil Removal Filter
(includes separator elements, oil removal elements & drain rebuild kit)
HPRPMK47S HPRPMK47S HPRPMK47S HPRPMK48S HPRPMK48S HPRPMK48S HPRPMK48S
Rebuild Kit - Automatic Drain
3210722 3210722 3210722 3210722 3210722 3210722 3210722
