11
MODELS 1200 1600 2000 2300
MINIMUM - MAXIMUM OPERATING CONDITIONS
Max. Inlet Air Pressure ( compressed air @ inlet dryer ) Std. 200 psig (14 bar)
Optional 300 psig (21 bar)
Max. Inlet Air Temperature (compressed air @ inlet dryer) 120°F (49°C)
Min.- Max. Ambient Temperature (Air Cooled) 35°F (1.7°C) -110°F (43°C)
Min.- Max. Ambient Temperature (Water Cooled) 35°F (1.7°C) -130°F (54°C)
REFRIGERATION SYSTEM DATA
Condensing Unit Mfg. Copeland
Compressor Type Hermetic Scroll / Non-cycling
Refrigeration Compressor Horsepower 6 7-1/2 10 12
BTU/HR - Refrigeration Only @ 35°F (1.7°C) Evaporator
& 100°F (38°C) Ambient 60/50 Hz 57310 / 47758 69370 / 57808 92550 / 77125 106090 / 88408
Outlet Air Temperature (nominal at rated conditions) 85°F (29°C)
Refrigerant Type R-404A R-404A R-404A R-404A
Refrigerant Charge See dryer serial number tag
Suction Pressure Setting psig (bar) 78 (5.4) 78 (5.4) 78 (5.4) 78 (5.4)
Compressor Control Ranges (out/in) (psig) A/C High 450 - 350 450 - 350 450 - 350 450 - 350
A/C Low 67 - 84 67 - 84 67 - 84 67 - 84
Compressor Control Ranges (out/in) (psig ) W/C High 320 - 280 320 - 280 320 - 280 320 - 280
W/C Low 67 - 84 67 - 84 67 - 84 67 - 84
Condenser Fan Switch Setting (in/out) (psig) Fan 1 300 - 230 300 - 230 300 - 230 300 - 230
(air-cooled models only) Fan 2 325 - 255 325 - 255 325 - 255 325 - 255
Air Flow Across Condenser (cfm) 60/50 Hz 4230 / 3525 5300 / 4417 4900 / 4083 4900 / 4083
CONDENSER COOLING WATER REQUIREMENTS (water cooled models)
Recommended Water Pressure (psig) * 40 Min. - 120 Max.
gpm of water @ 85°F cooling water 60/50 Hz 14 / 12 21 / 18 27 / 23 35 / 30
ELECTRICAL DATA
Nominal Voltage 208-230/3/60 208-230/3/60 208-230/3/60 208-230/3/60
Max. - Min. Voltage 253 - 187 253 - 187 253 - 187 253 - 187
Amperage Draw Total Full Load ** 26.9 39.3 53.1 62.8
Compressor Rated Load (amps) 23.9 30.9 44.9 54.4
Compressor Locked Rotor (amps) 156 189 278 350
Unit Protection Fuse Size (amps) ** 30 45 60 70
Branch Circuit Fuse Size (amps) Max. *** 50 70 100 125
Watts @ 35°F (1.7°C) Evaporator & 100°F (38°C) Ambient 7540 9630 14370 17490
Resistance (ohms) Three phase (total) - - - -
Nominal Voltage 460/3-60 460/3-60 460/3-60 460/3-60
Max. - Min. Voltage 506 - 414 506 - 414 506 - 414 506 - 414
Amperage Draw Total Full Load ** 11.1 20 25.5 29.6
Compressor Full Load (amps) 9.3 16.2 21.7 25.8
Compressor Locked Rotor (amps) 70 94 127 158
Unit Protection Fuse Size (amps) ** 15 25 30 35
Branch Circuit Fuse Size (amps) Max. *** 20 40 50 60
Watts @ 35°F (1.7°C) Evaporator & 100°F (38°C) Ambient 7540 9630 14370 17490
Resistance (ohms) Three phase (total) - - - -
Nominal Voltage 200-220/3/50 200-220/3/50 200-220/3/50 200-220/3/50
Max. - Min. Voltage 242 - 180 242 - 180 242 - 180 242 - 180
Amperage Draw Total Full Load ** 26.9 39.3 53.1 62.8
Compressor Rated Load (amps) 23.9 30.9 44.9 54.4
Compressor Locked Rotor (amps) 156 189 278 350
Unit Protection Fuse Size (amps) ** 30 45 60 70
Branch Circuit Fuse Size (amps) Max. *** 50 70 100 125
Watts @ 35°F (1.7°C) Evaporator & 100°F (38°C) Ambient 6283 8025 11975 14575
Resistance (ohms) Three phase (total) - - - -
Nominal Voltage 400/3/50 400/3/50 400/3/50 400/3/50
Max. - Min. Voltage 462 - 342 462 - 342 462 - 342 462 - 342
Amperage Draw Total Full Load ** 11.1 20 25.5 29.6
Compressor Rated Load (amps) 9.3 16.2 21.7 25.8
Compressor Locked Rotor (amps) 74 99 127 167
Unit Protection Fuse Size (amps) ** 15 25 30 35
Branch Circuit Fuse Size (amps) Max. *** 20 40 50 60
Watts @ 35°F (1.7°C) Evaporator & 100°F (38°C) Ambient 6283 8025 11975 14575
Resistance (ohms) Three phase (total) - - - -
Nominal Voltage 575/3/60 575/3/60 575/3/60 575/3/60
Max. - Min. Voltage 632 - 518 632 - 518 632 - 518 632 - 518
Amperage Draw Total Full Load ** 9.3 15.2 20 24
Compressor Rated Load (amps) 7.9 11.8 16.6 20.6
Compressor Locked Rotor (amps) 54 74 100 125
Unit Protection Fuse Size (amps) ** 12-1/2 17-1/2 25 30
Branch Circuit Fuse Size (amps) Max. *** 15 25 40 50
Watts @ 35°F (1.7°C) Evaporator & 100°F (38°C) Ambient 7540 9630 14370 17490
Resistance (ohms) Three phase (total) - - - -
* Allows continued operation with some restriction in the water strainer, * * Air cooled models only, * * * HACR type per NEC
ENGINEERING DA TA
