HANKISON PR500 User Manual

9
OPERATING PRESSURE psig / kg/cm
2
AIR FLOW 60 / 4.2 100 / 7 180 / 12.6 200 / 14.0
2.0 x rated flow 5.4 3.5 2.1 1.9
1.5 x rated flow 3.2 2.1 1.2 1.1
1.2 x rated flow 2.1 1.4 0.8 0.7
OUTLET DEWPOINT
DEW POINT
TEMPERATURE MULTIPLIER
°F °C
38 3 1.0
40 4 1.1
45 7 1.2
50 10 1.3
COOLING MEDIUM*
AMBIENT
TEMPERATURE MULTIPLIER
°F °C
80 27 1.12
90 32 1.06
100 38 1.00
110 43 0.94
INLET COMPRESSED AIR CONDITIONS
INLET INLET TEMPERATURES
PRESSURES 80°F90°F 100°F 110°F 120°F
psig kg/cm
2
27°C32°C38°C 43°C49°C
50 3.5 1.35 1.05 0.84 0.69 0.56
80 5.6 1.50 1.17 0.95 0.79 0.66
100 7.0 1.55 1.23 1.00 0.82 0.70
125 8.8 1.63 1.31 1.07 0.91 0.74
150 10.5 1.70 1.37 1.13 0.95 0.80
175 12.3 1.75 1.42 1.18 0.99 0.84
200 14.0 1.80 1.47 1.22 1.03 0.89
scfm x 0.0286 = m
3
/min
TABLE 2
Air capacity correction factors (multipliers)
TABLE 3
Pressure drop correction factors (multipliers)
* Air-cooled models; water-cooled models use 1.15 multiplier if cooling
water is below 95°F, 35°C
TABLE 1
Rated capacity and Pressure @ 100 psig inlet pressure,
100°F inlet temperature, and 100°F ambient temperature
MODEL 500 600 700 800 1000 1200 1600 2000 2300
scfm scfm scfm scfm scfm scfm scfm scfm scfm
Rated Capacity of 60 Hz 500 600 700 800 1000 1200 1600 2000 2300
Air-Cooled Models (scfm) 50 Hz 500 560 580 745 830 1000 1330 1660 1910
Pressure Drop (psi) 60 Hz 3.2 3.6 4.0 3.6 4.2 4.1 3.9 4.7 5.0
50 Hz 3.2 3.2 2.9 3.2 3.0 2.9 2.8 3.4 3.6
n
SIZING
Determining dryer capacity at actual operating conditions
To determine the maximum inlet flow capacity of a dryer at various operating conditions, multiply the rated capacity from
Table 1 by the multipliers shown in Table 2.
EXAMPLE: How many scfm can a model 1000 handle when the compressed air to be dried is at 80 psig and 90°F; ambient air
temperature is 80°F; and a 38°F dew point temperature is desired?
ANSWER: 1000 x 1.17 x 1.12 x 1.0 = 1310 scfm.
Pressure Drop
To determine pressure drop at increased flows, multiply the pressure drop at rated conditions from Table 1 by the multiplier
shown in Table 3 for the appropriate air flow rate and operating pressure.
EXAMPLE: What is the pressure drop across a model 1000 when flowing 1500 scfm at 200 psig ?
ANSWER: 1500/1000 = 1.5; multiplier below at 1.5 and 200 psi = 1.1; 1.1 x 4.2 psi = 4.6 psi.
