HANKISON PR500 User Manual

18
Parts Description 1600 2000 2300
Voltage 208 400/3/50 575/3/60 208 400/3/50* 575/3/60 208 400/3/50* 575/3/60
230/3/60 460/3/60 230/3/60 460/3/60 230/3/60 460/3/60
Condensing unit (Air-cooled) 4130.129.9 4130.129.10 4130.129.11 4130.129.12 4130.129.13 4130.129.14 4130.129.15 4130.129.16 4130.129.17
Compressor 4130.106.61 4130.106.50 4130.106.62 4130.106.63 4130.106.51 4130.106.64 4130.106.65 4130.106.52 4130.106.66
Crankcase Heater 5920.330.20 5920.330.17 5920.330.21 5920.330.20 5920.330.17 5920.330.21 5920.330.20 5920.330.17 5920.330.21
Contactor 5910.135.12 5910.135.19 5910.135.19 5910.135.16 5910.135.19 5910.135.19 5910.135.16 5910.135.19 5910.135.19
Aux Contactor NO —- —- —- —- —- —- —- —- —-
Aux Contactor NC —- —- —- —- —- —- —- —- —-
Aux Contactor NC\NO 6110.101.20 6110.101.20 6110.101.20 6110.101.20 6110.101.20 6110.101.20 6110.101.20 6110.101.20 6110.101.20
Control Circuit Transformer 6120.092.1 6120.092.1 6120.093.6 6120.092.1 6120.092.1 6120.093.6 6120.092.1 6120.092.1 6120.093.6
Fuse, Control Circuit 5920.274.20 5920.274.20 5920.274.20 5920.274.20 5920.274.20 5920.274.20 5920.274.20 5920.274.20 5920.274.20
Fuse, Primany Transformer 5920.274.19 5920.274.19 5920.274.19 5920.274.19 5920.274.19 5920.274.19 5920.274.19 5920.274.19 5920.274.19
Power Transformer —- —- —- —- —- —- —- —- —-
Fuse, Power Transformer —- —- —- —- —- —- —- —- —-
High Refrigerant Pressure Switch
(Air-cooled) 4130.138.28 4130.138.28 4130.138.28 4130.138.28 4130.138.28 4130.138.28 4130.138.28 4130.138.28 4130.138.28
High Refrigerant Pressure Switch
(Water-cooled) 4130.139.2 4130.139.2 4130.139.2 4130.139.2 4130.139.2 4130.139.2 4130.139.2 4130.139.2 4130.139.2
Low Refrigerant Pressure Switch 4130.138.29 4130.138.29 4130.138.29 4130.138.29 4130.138.29 4130.138.29 4130.138.29 4130.138.29 4130.138.29
Discharge Temperature Switch —- —- —- —- —- —- —- —- —-
Solid State Motor Protector 5925.580.7 5925.580.7 5925.580.7 5925.580.7 5925.580.7 5925.580.7 5925.580.7 5925.580.7 5925.580.7
On/Off Switch 6110.706.6 6110.706.6 6110.706.6 6110.706.6 6110.706.6 6110.706.6 6110.706.6 6110.706.6 6110.706.6
Light - Red 6350.457.12 6350.457.12 6350.457.12 6350.457.12 6350.457.12 6350.457.12 6350.457.12 6350.457.12 6350.457.12
Light - Green 6350.457.11 6350.457.11 6350.457.11 6350.457.11 6350.457.11 6350.457.11 6350.457.11 6350.457.11 6350.457.11
Hight Temperature Light Sensor 5930.189.1 5930.189.1 5930.189.1 5930.189.1 5930.189.1 5930.189.1 5930.189.1 5930.189.1 5930.189.1
Hot Gas By-pass Valve 4130.690.19 4130.690.19 4130.690.19 4130.690.19 4130.690.19 4130.690.19 4130.690.19 4130.690.19 4130.690.19
Thermal Expansion Valve 4130.829.16 4130.829.16 4130.829.16 4130.829.17 4130.829.17 4130.829.17 4130.829.18 4130.829.18 4130.829.18
Filter Dryer (liquid line) 4130.166.4 4130.166.4 4130.166.4 4130.166.4 4130.166.4 4130.166.4 4130.166.4 4130.166.4 4130.166.4
Sight Glass 4130.725.4 4130.725.4 4130.725.4 4130.725.4 4130.725.4 4130.725.4 4130.725.4 4130.725.4 4130.725.4
De-Superheating Valve 4130.829.19 4130.829.19 4130.829.19 4130.829.20 4130.829.20 4130.829.20 4130.829.20 4130.829.20 4130.829.20
Suction Filter 4130.246.1 4130.246.1 4130.246.1 4130.246.1 4130.246.1 4130.246.1 4130.246.1 4130.246.1 4130.246.1
Condenser (Air-cooled) 4130.111.16 4130.111.16 4130.111.16 4130.111.16 4130.111.16 4130.111.16 4130.111.16 4130.111.16 4130.111.16
Condenser (Water-cooled) 4130.115.12 4130.115.12 4130.115.12 4130.115.12 4130.115.12 4130.115.12 4130.115.12 4130.115.12 4130.115.12
Cooling Water Regulating Valve 4130.145.3 4130.145.3 4130.145.3 4130.145.5 4130.145.5 4130.145.5 4130.145.6 4130.145.6 4130.145.6
Cooling Water Strainer 4731.735.2 4731.735.2 4731.735.2 4731.735.3 4731.735.3 4731.735.3 4731.735.4 4731.735.4 4731.735.4
Cooling Water Strainer Screen 4731.735.7 4731.735.7 4731.735.7 4731.735.8 4731.735.8 4731.735.8 4731.735.9 4731.735.9 4731.735.9
Fan Motor 6105.238.50 6105.238.25 6105.238.51 6105.238.50 6105.238.25 6105.238.51 6105.238.50 6105.238.25 6105.238.51
Fan Blade 4140.227.15 4140.227.15 4140.227.15 4140.227.15 4140.227.15 4140.227.15 4140.227.15 4140.227.15 4140.227.15
Fan Cut-out Switch (Fan 1) 4130.138.26 4130.138.26 4130.138.26 4130.138.26 4130.138.26 4130.138.26 4130.138.26 4130.138.26 4130.138.26
Fan Cut-out Switch (Fan 2) 4130.138.27 4130.138.27 4130.138.27 4130.138.27 4130.138.27 4130.138.27 4130.138.27 4130.138.27 4130.138.27
Air Pressure Gauge 6685.279.1 6685.279.1 6685.279.1 6685.279.1 6685.279.1 6685.279.1 6685.279.1 6685.279.1 6685.279.1
Air Temperature Gauge 6685.281.6 6685.281.6 6685.281.6 6685.281.6 6685.281.6 6685.281.6 6685.281.6 6685.281.6 6685.281.6
Suction Pressure Gauge 6685.287.3 6685.287.3 6685.287.3 6685.287.3 6685.287.3 6685.287.3 6685.287.3 6685.287.3 6685.287.3
Head Pressure Gauge 6685.279.2 6685.279.2 6685.279.2 6685.279.2 6685.279.2 6685.279.2 6685.279.2 6685.279.2 6685.279.2
Digital Panel 03.5817-01 03.5817-01 03.5817-01 03.5817-01 03.5817-01 03.5817-01 03.5817-01 03.5817-01 03.5817-01
Sensor (set of 4) 6625.471.3 6625.471.3 6625.471.3 6625.471.3 6625.471.3 6625.471.3 6625.471.3 6625.471.3 6625.471.3
MECHANICAL DRAIN
Repair Parts Kit 05.7501-03 05.7501-03 05.7501-03 05.7501-03 05.7501-03 05.7501-03 05.7501-03 05.7501-03 05.7501-03
ELECTRIC DRAIN
Timer 5945.693.4 5945.693.4 5945.693.4 5945.693.4 5945.693.4 5945.693.4 5945.693.4 5945.693.4 5945.693.4
Coil and Valve 4810.741.38 4810.741.38 4810.741.38 4810.741.38 4810.741.38 4810.741.38 4810.741.38 4810.741.38 4810.741.38
(*) For 400/3/50 use control transformer 6120.093.6
PAR TS LIST
