Setup/Installation 19
Logged data on the edge
pH
® can be transferred from the meter to a PC by
following these simple directions. Suitable operating systems include Windows
(Xp minimum), OS X or Linux.
1. Connect edge
pH
® to the PC using the supplied micro USB cable.
2. Turn on edge
pH
®.
3. Press SETUP and select “LOG ON EDGE”
4. Press MODIFY then use pq keys to change to “EXPORT TO USB”
5. Press CFM and the USB/PC Tag is displayed.
6. Press SETUP to exit
The PC should detect the USB as a removable drive. Open the drive to view the
stored les. Log les are formatted as Comma separated values (*.CSV) and can
be opened with any text editor or spreadsheet program.
Note:
• Western Europe (ISO-88859-1) character set and English language are
suggested settings.
• Other les may be visible depending upon computer settings. All les
stored will appear in this folder.
• Adjust Font or column width appropriately. Adjust the decimal places if the
pH was logged with 0.001 resolution.
Interval logs are designated as pH or mV Lots. ie. PHLOT001, MVLOT002.
The Manual Lots are PHLOTMAN for pH and MVLOTMAN for ORP.
The Stability Lots are PHLOTSTAB for pH and MVLOTSTAB for ORP. All stability
logs, regardless of stability setting, are located in the same stability le for that
measurement.
Click on the desired log to view data.
Note:
• If “ºC !” appeared in log data, the electrode/probe was used beyond it’s
operation speci cations and the data is not considered reliable.
• If “ºC !!” appeared in log data, the temperature sensor within the probe or
electrode is broken and the device should be replaced. Logged data should
not be considered reliable.
PC & Storage
Interface
