Hansa C5 - Specifications

Hansa C5 O&M Manual - OM-025 Revision A 13/02/2020
© Hansa Chippers 2020
19
Specifications
C5
General
Length
1165 mm
Width
560 mm
Height
1200 mm
Weight
67 kg
Motor
Make & model
Honda GP200
Max Power
6.5 HP
Cutting System
Disc speed
3600 RPM
Disc dimensions
286 x 10 mm
Shaft diameter
25 mm
Knives
1
Feed System
Chipping capacity
60 mm
Feed type
Gravity fed, self-feeding
Inlet chute opening
100 x 130 mm
Discharge System
Discharge height
600 mm
Outlet chute type
Fixed
