Time Range
8ns ~ 10s
Under Amp Trigger
Polarity
Positive, Negative
Condition
<, >, !=, =
Source
CH1~CH2
Time Range
8ns ~ 10s
UART Trigger
Condition
Start, Stop, Data, Parity Error, COM Error
Source
CH1~CH2
Data format
Hex
Condition
<, >, !=, =
Data Length
1 byte
Data Bits Width
5 bit, 6 bit, 7 bit, 8 bit
Parity Check
None, Odd, Even
Idle Level
High, Low
Baud Rate (Selectable)
110/300/600/1200/2400/4800/9600/14400/19200/38400/57600/115200/230400/380400
/460400 bit/s
Baud Rate (Custom)
300bit/s~334000bit/s
LIN Trigger
Condition
Interval Field, Sync Field, Id field, Sync Id Error, Identifier, Id and Data
Source
CH1~CH2
Data format
Hex
Baud Rate (Selectable)
110/300/600/1200/2400/4800/9600/14400/19200/38400/57600/115200/230400/380400
/460400 bit/s
Baud Rate (Custom)
300bit/s~334000bit/s
CAN Trigger
Condition
Start Bit, Remote Frame, Data Frame Id, Frame Id, DataFrame Id A, Error Frame, All Error,
Ack Error, Overload Fram
Source
CH1~CH2
Data format
Hex
Baud Rate (Selectable)
10000, 20000, 33300, 500000, 62500, 83300, 100000, 125000, 250000, 500000, 800000,
1000000
Baud Rate (Custom)
5kbit/s~1Mbit/s
SPI Trigger
Source (SDA/SCL)
CH1~CH2
Data format
Hex
Data Length
4, 8, 16, 24, 32
IIC Trigger
