Hantek DSO2C10 User Manual

7 / 72
DSO2000 series digital storage oscilloscope introduction
DSOXXXX Series oscilloscopes cover the bandwidths from 100MHz to 150MHz, and provide the
real-time up to 1GSa/s. In addition, they have 7 inchs color TFT LCD as well as WINDOWS-style
interfaces and menus for easy operation.
What’s more, the plenty menu information and the easy-to-operate buttons allow you to gain
information as much as possible in measurement; the Multifunctional Knobs and the powerful shortcut
keys help you save a lot of time in operation; the Auto Scale function lets you detect sine and square
waves automatically.
Model
Channels
Bandwidth
Storage depth
Sample Rate
AFG
DSO2C10
2
100MHz
8M
1GS/s
—
DSO2C15
2
150MHz
8M
1GS/s
—
DSO2D10
2
100MHz
8M
1GS/s
√
DSO2D15
2
150MHz
8M
1GS/s
√

Hantek DSO2C10 Specifications

General

Bandwidth	100 MHz
Channels	2
Sample Rate	1 GSa/s
Memory Depth	8 Mpts
Trigger Types	Edge, Pulse, Video, Slope, Alternative
Display Resolution	800 x 480 pixels
FFT	Yes
Math Functions	+, -, *, /, FFT
Power Supply	100-240 V AC, 50/60 Hz
Display	7 inch LCD
Vertical Resolution	8-bit
Interface	USB host, USB device
Input Impedance	1 MΩ ± 2%
Waveform Capture Rate	50, 000 wfm/s
