Hantek HDG2000B Series - Enable Arbitrary Waveform; Select Arbitrary Waveform

User Manual 23
3.1 Enable Arbitrary Waveform
Press Arb to enable arbitrary waveform function and open the operation menu of arbitrary
waveform.
Frequency/Period: set the "Frequency/Period" of the arbitrary waveform.
Amplitude/HighLevel: set the "Amplitude/HighLevel" of the arbitrary waveform.
Offset/LowLevel: set the output "Offset/LowLevel" of the arbitrary waveform.
Phase: set the "Start Phase" of the arbitrary waveform.
Align Phase: refer to "Align Phase".
Type: select the built-in waveforms or user-defined arbitrary waveforms stored in external
memory of the instrument.
3.2 Select Arbitrary Waveform
HDG2000B allows the user to select any of the internal or external memory of the device for
waveform output.
Press “Arb” softkey, then press “type” softkey to select the instrument built-in waveform output.
Select more than 160 kinds of arbitrary waveform built in HDG2000B, as shown in the following
table. Press "type", select a type ("Math", "Project", "Distribution function" and "Trigonometric
function", "Window function" and "biology"), and press the corresponding softkey type to select
the desired waveform. Press Return key to return to main menu.
Name
Description
Common
DC
DC signal
AbsSine
Absolute value of a Sine
AbsSineHalf
Absolute value of half a Sine
AmpALT
Gain oscillation curve
AttALT
Attenuation oscillation curve
GaussPulse
Gauss pulse
NegRamp
Negative ramp
NPulse
Negative pulse
PPulse
Positive pulse
SineTra
Sine-Tra waveform
SineVer
Sine-Ver waveform
StairDn
Stair-down waveform
StairUD
Stair-up and stair-down waveform
StairUp
Stair-up waveform
Trapezia
Trapezoid waveform
Project
BandLimited
Bandwidth-limited signal
BlaseiWave
Time-velocity curve of explosive vibration
