User Manual 67
7.7 Trigger Output Edge
In burst mode, when the trigger source is "Internal" or "Manual", the generator would output a
TTL-compatible signal with specified edge from the [Sync/Mod/Trig] connector at the front panel.
Internal trigger: The generator outputs a square waveform with variable duty cycle (related
to the carrier period and number of cycles) from the [Sync/Mod/Trig] connector at the start of
burst. The trigger period is the same with the specified burst period.
Manual trigger: The generator outputs a pulse from the [Sync/Mod/Trig] connector at the
start of burst.
External trigger: The [Sync/Mod/Trig] connector is used as the input terminal of external
trigger signal and has no trigger output.
