User Manual 31
Chapter 5 Modulated Waveform
HDG2000B supports AM, DSB-AM, FM, PM, 2ASK, 2FSK, 2PSK, BPSK, QPSK, 3FSK, 4FSK,
OSK and PWM modulations. It can output modulated waveform from a single channel or from two
channels at the same time. The modulated waveform consists of carrier waveform and modulating
waveform. The carrier waveform can be Sine, Square, Ramp, Pulse, Arbitrary waveform (except
DC) or Harmonic. The modulating waveform can be from internal (default), other channel, or
external modulation source.
AM Modulation
DSB-AM Modulation
FM Modulation
PM Modulation
2ASK Modulation
2FSK Modulation
2PSK Modulation
BPSK Modulation
QPSK Modulation
3FSK Modulation
4FSK Modulation
OSK Modulation
PWM Modulation
