Hantek HDG2000B Series - Appendix A Specifications

User Manual 87
Appendix A Specifications
All technical specifications are applicable to HDG2000B series signal generator. Unless otherwise
specified, all technical specifications are guaranteed when the following two conditions are
established.
 The signal generator is in the calibration period.
 The signal generator runs continuously for more than 30 minutes at the specified operating
temperature (18 ~28 C).
The specifications used are guaranteed except those marked "typical".
Model
HDG2102B
HDG2082B
HDG2062B
HDG2032B
Channel
2
2
2
2
Memory Depth
64M
64M
64M
64M
Maximum
Frequency
100MHz
80MHz
60MHz
30MHz
Sample Rate
500MSa/s
Voltage
Resolution
16Bit
Digital Output
16 Channels output
Waveforms
Standard
Waveforms
Sine, Square, Ramp, Pulse, Noise, Harmonics
Arbitrary
Waveforms
More than 160 kinds, including Sinc, Exponential Rise, Exponential Fall, ECG,
Gauss, Haver Sine, Lorentz, Dual-Tone, DC, etc.
Frequency Characteristics
Sine
1uHz~100MHz
1uHz~80MHz
1uHz~60MHz
1uHz~30MHz
Square
1uHz~30MHz
1uHz~30MHz
1uHz~30MHz
1uHz~30MHz
Pulse
1uHz~15MHz
1uHz~15MHz
1uHz~15MHz
1uHz~15MHz
Ramp
1uHz~4MHz
1uHz~4MHz
1uHz~4MHz
1uHz~4MHz
Noise
100MHz
80MHz
60MHz
30MHz
Harmonics
1uHz~15MHz
1uHz~15MHz
1uHz~15MHz
1uHz~15MHz
Arb.
1uHz~20MHz
1uHz~20MHz
1uHz~20MHz
1uHz~20MHz
Resolution
1uHz
Accuracy
±2ppm, 18~28℃
Sine Wave Spectrum Purity
Harmonic
Distortion
Typical（0dBm）
DC-1MHz: <-60dBc;
1MHz-10MHz: <-55dBc;
10MHz-100MHz: <-50dBc
Total Harmonic
Distortion
<0.1% (10Hz-20kHz, 0dBm)
