Tablet1000 Quick guide Copyright © Qingdao Hantek Electronics Co., LTD
10
4 Product introduction
The new generation of handheld tablet oscilloscope, TO1000 series: Using 7 inch
industrial specification TFT-LCD 800*480 resolution liquid crystal display, supporting
multi-touch capacitive operation; Three functions, which are oscilloscope, signal source,
multimeter; Two or four analog channels; Built-in signal source supporting 25MHz
standard waveform output, a variety of built-in arbitrary waves; Data recording function
provided by the multimeter, which can monitor and record voltage, current, resistance
and other data changes for a long time and generate the trend chart; Standard
9V2A/5V3A/12V1.5A charger, Type - C input interface, can share a charging device with
a mobile phone; Powered by 4 or 2 18650 lithium batteries; With a supporting stand,
able to use and place anywhere.
4.1 Front panel
Figure 4.1 Front panel41
