29
9-3. Alarm Output
9-4. Retransmission Output
9-2. Countrol output
Relay
contact output
Contact capacity : 240 V AC 3 A, 30 V DC 3 A (resistive load)
Contact : 1C
Output operation : P.I.D control, ON / OFF
Proportional cycle : 1 ~ 1000 sec.
Output limit : 0.0 ~ 100.0 % range, higher limit(OL-H) or lower limit(OL-L)
selectable (valid when AT)
ON/OFF hysteresis : 0 ~ 100 %
Time resolution : 0.1 % or 10 ms
SSR drive
voltage output
ON voltage : 25 V DC min.(resistive load 600Ω min., 30mA limit when short)
OFF voltage : 0.1 V DC max.
Proportional cycle : 1 ~ 1000 sec.
Output operation : P.I.D control
Output limit : 0.0 ~ 100.0 % range, higher limit(OL-H) or lower limit(OL-L)
selectable (valid when AT)
Time resolution : 0.1 % or 10 ms
(Current output)
SCR output
(4 - 20 A DC)
Current output range : 4 ~ 20 mA DC
Resistive load : 600Ω max.
Accuracy : ±0.3 % of full scale (4 ~ 20 mA range), Resolution : Approx. 3,000
Output ripple : 0.1 % (P-P) of max. scale (150 Hz)
Sampling time : 250 mS
Output operation : P.I.D control
Output limit : -5.0 ~ 105.0 % range, higher limit(OL-H) or lower limit(OL-L)
selectable (valid when AT)
Relay output
Contact capacity : 240 V AC 1 A, 30 V DC 1 A (resistive load)
Setup point : 1a× 2
Output : ON / OFF
Dead band : 0.0 ~ 100.0 % EUS
Retransmission
output
Current output range : 4 - 20 mA DC
Resistive load : 600 Ω max.
Accuracy : ±0.3 % of max. scale (4 - 20mA range)
Resolution : Approx. 3,000
Output ripple : 0.1 % (P-P)max. of scale (150Hz)
Sampling : 250 ms
Power supply for external sensor : 24 V DC 20 mA Max.
※ If selecting SPS in the retransmission group, power supply for external sensor will be outputed from
terminal ⑥ & ⑦.
