9-12. Function
Measuring
Input
Bias
-100.0 ~ 100.0 % for measuring input range
Valid setting a correction value.
Scaling
According to setup of SL-H, SL-L of measuring range, scaling
is available.
Filter OFF, 1 ~ 120 sec.
Control
Pattern 2 Patterns
Segment 10 Segments / 1 pattern
PID Group 4 Kinds
Auto Tuning According to SV, AT is operating. 〔Selection STD or Low PV〕
Proportional Band (P) 0.1% - 999.9 %.
Integral Time (I) OFF, 1 - 6000 sec.
Differential Time (D) OFF, 1 - 6000 sec.
ON, OFF Control Select ON-OFF control in output group.
Manual Reset -0.5 ~ 105.0 %. 〔Valid when I=OFF〕
Direct/Reverse action Select Direct or Reverse action in output group.
Emergency (Preset) -0.5 ~ 105.0 % of output value.
ON/OFF Hysteresis
0.0 ~ 100.0 % of range.
When selecting ON/OFF control, follow the HYS set up of output
group.
Auto/Man Changeable by front button
ARW AUTO, 50.0 ~ 200.0 % at the PID group.
Fuzzy
OFF, ON select. (Select ON in the control setup group of fuzzy
function selection mode.)
Retransmission
Retransmission Signal Select among PV, SV, MV and SPS.
Scaling
Possible to set up (PV, SV), set up upper limit of transmission
output and the lowest limit.
SPS 24 V DC 20 mA max
Alarm
Setup Point 2 points. (max.)
Type of Alarm High / Low alarm, High / Low deviation alarm.
Setup Range
Process alarm : 0 ~ 100 % of Range.
Deviation alarm : -100 ~ 100 % of Range.
Alarm Hysteresis 0.0 ~ 100.0 % of instrument range.
