31
9-9. Power Supply
Rated voltage 100 - 240 V AC, 50 - 60 Hz
Tolerable voltage
regulation
±10 % of rated voltage
Power consumption MAX 10 VA(6.0 W max)
9-10. Insulation Resistance
Primary terminal Secondary terminal MIN. 500 V DC 20 MΩ
Primary terminal Ground MIN. 500 V DC 20 MΩ
Ground Secondary terminal MIN. 500 V DC 20 MΩ
9-11. Dielectric strength
Primary terminal Secondary terminal 2300 V AC 50/60 Hz for 1 minute
Primary terminal Ground 2300 V AC 50/60 Hz for 1 minute
FG Secondary terminal 1500 V AC 50/60 Hz for 1 minute
