30
9-5. Communication Interface
9-6. Operating Environment
9-7. Storage Condition
9-8. Structure
Standard EIA RS485
Communication address 31, 1~99 setting available
Communication method 2 wire half duplex
Synchronization Start-stop synchronous mode
Communication sequence None
Communication distance 1.2Km max.
Communication speed 600, 1200, 2400, 4800, 9600 BPS
Start bit 1 BIT
Data bit 7 or 8 BIT
Parity bit None, even numbers, odd numbers
Stop bit 1 or 2 BIT
Communication protocol PC LINK
Response time
Reception treatment time + (Response time × 10mS)
Installation environment
Continuous vibration (5 ~ 14 Hz) : Forward width 1.2 mm max.
(4 ~ 150 Hz) : 4.9 ㎨ (0.5 G) max.
Vibration : 14.7 ㎨ (1.5 G), 15 sec. max. (each 3 direction)
Shock : 147 ㎨ (15 G), 11msec max. (6 direction each 3 times)
Normal operation
condition
Ambient temperature : 0 ~ 50 ℃
Ambient humidity : 35 ~ 85 % RH (no condensation)
Influence of magnetic : 400 AT/m max.
Influence of ambient
temperature
Warm-up time : 30 min. min.
T/C, Voltage input : ±1 μV/℃ or ±0.01 %/℃ of F.S.
R.T.D input : ±0.05 Ω/℃ max.
Analog output : ±0.05 % of F.S / ℃ max. (continuous output)
Influence of voltage
regulation
Analog input : ±1 μV / 10 V or ±0.01 % of F.S. / 10 V
Analog output : ±0.05 % of F.S / 10 V max.
Storage temperature -25 ~ 70 ℃
Storage humidity 5 ~ 95 % RH (no condensation)
Shock 1 m max. in packing condition
Material Plastic case
Weight 696 g (including brackets & box)
Panel cutout 96(W) × 96(H) × 100(D)
