Harbor Breeze E-BDB52MBK5BC4N User Manual

* US Pat. No. 7351037
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
A
E
D
B
F
C
H
J
G
K
N
I
PACKAGE CONTENTS
R
Q
L
O
M
P
5
*
H
U
T
S
PART DESCRIPTION QUANTITY
N Switch Housing Cap 1
(preassembled)
O Lock Washer 10
(preassembled)
P Canopy Mounting Screw 4
(preassembled)
Q Pin (preassembled) 1
R Clip (preassembled)
1
S Light Kit Fitter Screw
3
(preassembled)
T Switch Housing Screw 3
(preassembled)
U Blade Screw 15
(preassembled)
PART DESCRIPTION QUANTITY
A Downrod 1
B Canopy 1
C Mounting Bracket 1
D Motor Housing 1
E* Plastic Locking Mechanism 5
F Light Kit Fitter 1
G Blade 5
H Blade Arm 5
I Glass Shade 4
J Candelabra Base Bulb 4
K Pull Chain Extension 2
L Socket Ring 4
(preassembled)
M Motor Screw 10
(preassembled)
