15HARDI
®
ATV SPRAYER DIAPHRAGM OPERATOR'S MANUAL
3.5 Power Supply
A 12 Volt DC power supply is required to operate the electrical boom
distribution valve solenoids (Fig. 5). Connect the power supply wiring
harness as follows:
Red wire to positive (+) and Black wire to negative (-).
IMPORTANT: Do not connect to the starter motor or generator/
alternator. Warranty is void if this is done.
The power supply wiring harness is equipped with a 7.5 Amp inline
fuse to protect the control box.
Fig. 5
DISTRIBUTION VALVE SOLENOIDS
