2 HARDI
®
ATV SPRAYER DIAPHRAGM OPERATOR'S MANUAL
TABLE OF CONTENTS
1.0 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.0 SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Follow Safety Instructions . . . . . . . . . . . . . . . . . . . 8
2.2 Operating the Sprayer Safely . . . . . . . . . . . . . . . . . 8
2.3 Handling Chemical Products Safely . . . . . . . . . . . . 10
2.4 Local Poison Information Center . . . . . . . . . . . . . . 11
3.0 HOOKING UP THE SPRAYER . . . . . . . . . . . . . . . . . . . . . . 12
3.1 Tow Vehicle Requirements . . . . . . . . . . . . . . . . . . . 12
3.2 Tongue Weight Adjustment . . . . . . . . . . . . . . . . . . 12
3.3 Hitch Height Adjustment . . . . . . . . . . . . . . . . . . . . . 13
3.4 Wheel Spacing Adjustment . . . . . . . . . . . . . . . . . . 14
3.5 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.6 Control Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.7 Gas Engine Requirements . . . . . . . . . . . . . . . . . . . 16
4.0 OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . 17
4.1 Filling The Main Tank . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 Filling The Handwash (Clean Water) Tank . . . . . . . 17
4.3 Standard Plumbing Diagram . . . . . . . . . . . . . . . . . 18
4.4 Plumbing Diagram with optional Rate Controller . . 19
4.5 Adjustment Of The Sprayer Controls . . . . . . . . . . . 20
4.6 Agitation Adjustment . . . . . . . . . . . . . . . . . . . . . . . 22
4.7 Operation Of The Tank Drain Valve . . . . . . . . . . . . 22
4.8 Adjustment Of Air Pressure in Pressure Damper . . 23
4.9 Unfolding/Folding Boom . . . . . . . . . . . . . . . . . . . . . 23
4.10 Boom Height Adjustment . . . . . . . . . . . . . . . . . . . . 24
5.0 NOZZLE SELECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.1 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
