27HARDI
®
ATV SPRAYER DIAPHRAGM OPERATOR'S MANUAL
HARDI
®
QUINTASTREAM
5 HOLE LIQUID FERTILIZER
NOZZLE Five streams of liquid
are distributed at different angles
and fl ows. Highest fl ow is from the
middle stream and lowest in the
outer; overlapping streams. This
allows for boom movements that
do not influence distribution.
Boom heights of 20" can be used
as safely as 30".
SOLID STREAM NOZZLE
for high volume liquid fertilizer
ap pli ca tion. In this application,
the 1553 nozzle is always used
with 330013 o-ring and 50, 80 or
100 mesh screens.
1553 less swirl
372011
thru
372019
LARGE DROPLET FLAT
SPRAY TIP IN 150 DEGREE
SPRAY ANGLE. Always used in
conjunction with 1553-14-16-18
or 20 cone nozzle. 50, 80 or 100
mesh screens are normally used
with these nozzles.
LARGE DROPLET HOLLOW
CONE NOZZLE for use where
drift must be kept to a minimum.
These nozzles must always be
fi tted with 1553 nozzles and grey
swirl plates. 50, 80 or 100 mesh
screens are normally used with
these nozzles.
371077
371551
HOLLOW CONE CERAMIC
NOZZLES for high pressure
and high volume fungicide and
insecticide application.
1299
