Water can be filled into the main tank in five ways:
1. Filled through tank lid.
2. Filled by diaphragm pump through a suction side fitted
filling device (optional extra) using normal pump
capacity directly to the tank.
3. Filled by diaphragm pump through a pressure side
fitted injector/venturi type Fast Filling Device (optional
extra) providing up to 3 times normal pump capacity.
4. Combination of 2 and 3.
5. Quick coupler for external filling
The tank should normally be filled 1/3 with water, before
adding the chemicals - always read instruction on
chemical container!
NOTE! Max. permitted tank contents:
IMPORTANT! If the sprayer is put aside with liquid in the
main tank all MANIFOLD valves must be closed.
1. Filling through tank lid
Remove tank lid and fill water through strainer to prevent
rust or other particles to enter the tank.
An overhead tank can be used in order to obtain high
filling capacity.
It is recommended to use as clean water as
possible for spraying purposes.
WARNING! DO NOT LET FILLING HOSE ETC. ENTER THE
TANK. KEEP IT OUTSIDE THE TANK, POINTING TOWARDS THE
FILLING HOLE.
IF THE HOSE IS LEAD TO THE BOTTOM OF THE TANK, AND THE
WATER PUMP AT THE WATER SUPPLY PLANT STOPS, CHEMI-
CALS CAN BE SIPHONED BACK AND CONTAMINATE THE
WATER SUPPLY LINES.
The valves and functions may vary from machine to
machine depending on optional equipment fitted. Only
the functions to be used must be open - Always close
remaining valves.
TT
TT
T
o opero oper
o opero oper
o oper
aa
aa
a
te the sprte the spr
te the sprte the spr
te the spr
aa
aa
a
ying functions:ying functions:
ying functions:ying functions:
ying functions:
Turn the handle on a green pressure valve towards
the function desired
Turn the handle on a black suction valve towards the
desired function
Open or close yellow disc (self-cleaning filter)
Close all remaining valves by setting the handle(s)
on O
NOTE! If a MANIFOLD valve is too tight to operate - or if
it is too loose (= liquid leakage), the 3-way-valve needs
to be serviced. Please see the part Occasional mainte-
nance - Adjustment of 3-way-valve for further informa-
tion. Correct setting is when the valve can be operated
smoothly by one hand
Electrical operated MANIFOLD valves (if
fitted)
One or more MANIFOLD valve(s) can be electrically
operated via a control box in the tractor cab. These can
only be operated manually when the power to the valve
motor is disconnected first.
Quick reference
A Quick Reference sticker follows this book.
It is meant to be fastened to the frame near to the
MANIFOLD SYSTEM for easy in field operation of the
valves.
T021-0012
027
QuicQuic
QuicQuic
Quic
k rk r
k rk r
k r
efef
efef
ef
erer
erer
er
enceence
enceence
ence
T060-0114
* On the assumption that the tyres can support the current load.
ledoM
retaw,emuloV
sresilitrefdiuqil,emuloV
ertiL lag.pmI lagSU ertiL lag.pmI
agSU
l002200224848.08545128.3746.865
l008200826162.93745128.3746.865
l002300234078.44800234078.448
l002400244298.801113238.0179.258
* Based on liquid fertilisers with specific gravity 1.3
)retlifgninaelc-fles(csidwolleY
The disc has two
positions; open
or closed
Closed
Open
