4
HARDI
®
FOAM MARKER STANDARD VERSION
Foam Marker Schematic
Fig. 1
Control Box
Compressor
Box
+12V
Foam
Solution
Tank
Foam
Dropper
Foam
Generators
-12V
Fuse
Foam
Dropper
