Page 44 of 87
Software upload HC5500
The HC5500 software version is shown every time the controller is switched on.
The communication cable without the
“Hardware halt” is plugged into the PC.
This is done before the computer is
powered up.
The communication cable with the
“Hardware Halt” is attached to the HC5500
in COM 1 (A) port).
Power ON the PC.
Power ON the HC5500
When the HC5500 is ON, the display will
write “Hardware halt”.
The controller awaits contact to the Hardi
HC5500 upgrade software programme.
On the PC, the upgrading program can be
started up and the PC dialogue box should
look like this.
The dialogue box shows what software
version will be uploaded to the HC5500
Controller.
Communication port has to be chosen.
If the Com port not is shown, select Scan
COM and see section “USB to RS232
Converter” how to find the Com port
number to use.
High-speed (CP2102) can only be used
with the HC6500 Controller.
