9 REAR-PANEL CONNECTIONS
Rear-Panel Connections
¡ AM Antenna: Connect theAM loop antenna
supplied with the receiver to these terminals.If an
externalAM antenna is used, make connections
to the AM and GND terminals in accordance
with the instructions supplied with the antenna.
™ FM Antenna: Connect the supplied indoor or
an optional external FM antenna to this terminal.
£ Remote IR Input: If the AVR 100’s front-
panel IR sensor is blocked due to cabinet
doors or other obstructions, an external IR
sensor may be used. Connect the output of
the sensor to this jack.
¢ Remote IR Output: This connection per-
mits the IR sensor in the receiver to serve other
remote-controlled devices. Connect this jack to
the “IR IN” jack on compatible equipment.
∞ Subwoofer Output: Connect this jack to
the line-level input of a powered subwoofer. If
an external subwoofer amplifier is used, con-
nect this jack to the subwoofer amplifier input.
§ DVD Inputs: Connect the analog audio
outputs and composite video output of a DVD
or LD player to these jacks.
¶ CD Inputs: Connect these jacks to the out-
put of a compact disc player or CD changer.
• Tape Inputs: Connect these jacks to the
PLAY/OUT jacks of an audio recorder.
ª Tape Outputs: Connect these jacks to the
RECORD/INPUT jacks of an audio recorder.
‚ Video Monitor Output: Connect this jack
to the composite video input of a TV monitor or
video projector to view the output of any stan-
dard video source selected by the receiver’s
video switcher.
⁄ Speaker Terminals: Connect these termi-
nals to the appropriate speakers, following the
designations shown.
NOTE: When making connections to the
Speaker Terminals always be certain to maintain
correct polarity between the speaker’s terminals
and those on the AVR by connecting red (+)
terminals to red, and black (–) terminals to
black. (See page 13 for more information on
speaker polarity.)
¤ Switched AC Outlet:This outlet may be
used to power any device that you wish to have
turn on when the unit is turned on with the
System Power Control switch 2.
NOTE: The power consumption of the device
plugged into this outlet ¤ should not exceed
100 watts.
‹ AC Power Cord: Connect the AC plug to a
nonswitched AC wall output.
› Coaxial Digital Inputs: Connect the coax
digital output from a DVD player, HDTV receiver,
LD player or CD player to these jacks.The signal
may be either a Dolby Digital signal or a standard
PCM digital source.
fi Optical Digital Input: Connect the opti-
cal digital output from a DVD player, HDTV
receiver, LD player or CD player to this jack.The
signal may be either a Dolby Digital signal or a
standard PCM digital source.
fl Video 2 Inputs: Connect these jacks to
the audio and video outputs of a TV Tuner,
Cable TV converter box, satellite receiver or any
other audio/video source.
‡ Video 1 Inputs: Connect these jacks to
the audio and video PLAY/OUT jacks of a VCR.
° Video 1 Outputs: Connect these jacks to
the audio and video RECORD/IN jacks of a VCR.
· 6-Channel Direct Inputs: If an external
digital audio decoder is used, connect the out-
puts of that decoder to these jacks.
