30 SETUP CODES
Setup Code Tables: VCR
Manufacturer/Brand Setup Code Number
AIWA 033
AKAI 017 040 042 100 101 115
AMPRO 088
AMSTRAD 123
ANAM 030 032 081
ASA 124
AUDIO DYNAMICS 013 023 037 040
BROKSONIC 034 036 102 135
CANDLE 124 125 127
CANON 027 030 032 125
CAPEHART 086
CITIZEN 124
CRAIG 005 038 108
CURTIS MATHES 030 032
DAEWOO 007 009 012 060 061 086 088 089 090 094 095 096
DAYTRON 088
DBX 013 023 037 040
DUAL 126
DYNATECH 033 049
ELECTROHOME 055
EMERSON 008 018 025 026 028 030 033 034 035 036 042 079
102 104 111
FERGUSON 126
FINLUX 123
FISHER 005 010 011 012
FUNAI 033
GE 030 032 059 068 085 087 113 116
GO VIDEO 105 109
GOLDSTAR 013 014 020 079 084 092 099
GRAETZ 126
HARMAN KARDON 013 041
HITACHI 006 033 040 059 110 119 139
INSTANTREPLAY 030 032
ITT 126
JCL 030 032
JC PENNEY 013 014 016 032 038 062 079
JENSEN 040
JVC 013 030 032 040 044 046 051 056 103 119 121
KENWOOD 015 037 040 044
LLOYD 033
LXI 014 015 033 079
MAGIN 038
MAGNAVOX 030 032 033 063 064
MARANTZ 013 030 032 063 065
MARTA 079
MATSUI 026 029
MEI 030 032
MEMOREX 005 012 015 030 032 033 049 068 079 107 112
MGA 041 042 055
MINOLTA 014 020
MITSUBISHI 014 020 041 042 045 047 055 057 120 133 134
MTC 123
MULTITECH 024 033
NAD 128
NATIONAL 129

Harman Kardon AVR 100 Specifications

Audio Specifications

stereo mode power	50 Watts per channel, 20Hz–20kHz, < 0.08% THD, 8 ohms
five-channel surround mode power (front channels)	40 Watts per channel, < 0.08% THD, 20Hz–20kHz, 8 ohms
five-channel surround mode power (center channel)	40 Watts, < 0.08% THD, 20Hz–20kHz, 8 ohms
five-channel surround mode power (surround channels)	40 Watts per channel, < 0.08% THD, 20Hz–20kHz, 8 ohms
input sensitivity/impedance	250mV/47k ohms
signal-to-noise ratio (IHF-A)	90dB
frequency response	10Hz–100kHz @ 1W (+0dB, –3dB)
high instantaneous current capability (HCC)	±30 Amps
transient intermodulation distortion (TIM)	0.08% (20Hz – 20kHz)
rise time	16 µsec
slew rate	40V/µsec

FM Tuner Specifications

frequency range	87.5–108MHz
usable sensitivity	1.5µV/14.8dBf
signal-to-noise ratio mono/stereo	73/70dB
distortion mono/stereo	0.3/0.5%
stereo separation	40dB @ 1kHz
selectivity	±400kHz, 60dB
image rejection	40dB
IF rejection	100dB
tuner output level	500mV @ 1kHz, ±75kHz Dev

AM Tuner Specifications

frequency range	520–1710kHz
signal-to-noise ratio	35dB
usable sensitivity	800µV/M
distortion	1kHz, 50% Mod 1.5%
selectivity	±10kHz, 30dB

Video Specifications

video format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response	10Hz–8MHz (–3dB)

General Specifications

power requirement	AC 120V/60Hz
power consumption	72W idle, 290W maximum (2 channels driven)
width	17.3 inches (440mm)
height	6.2 inches (156mm)
depth	14.7 inches (375mm)
weight	27.9 lb (12.6 kg)
