Harman Kardon AVR 100 User Manual

32 SETUP CODES
Setup Code Tables: DVD
Manufacturer/Brand Setup Code Number
CALIFORNIA AUDIO 038
DENON 005 022 025
GE 006 007
GOLDSTAR 008
HARMAN KARDON 001
JVC 009
KENWOOD 010
LOTTE 011 037
MAGNAVOX 012
MITSUBISHI 026
NAD 013
ONKYO 018
OPTIMUS 014
PANASONIC 027 028 035 042
PIONEER 015 023
RCA 021
RUNCO 030
SAMSUNG 034
SANYO 016
SHARP 024 031 040
SONY 017 032 039
TECHNICS 029
THOMSON 006 007
TOSHIBA 036 041
YAMAHA 019 020 033

Harman Kardon AVR 100 Specifications

Audio Specifications

stereo mode power	50 Watts per channel, 20Hz–20kHz, < 0.08% THD, 8 ohms
five-channel surround mode power (front channels)	40 Watts per channel, < 0.08% THD, 20Hz–20kHz, 8 ohms
five-channel surround mode power (center channel)	40 Watts, < 0.08% THD, 20Hz–20kHz, 8 ohms
five-channel surround mode power (surround channels)	40 Watts per channel, < 0.08% THD, 20Hz–20kHz, 8 ohms
input sensitivity/impedance	250mV/47k ohms
signal-to-noise ratio (IHF-A)	90dB
frequency response	10Hz–100kHz @ 1W (+0dB, –3dB)
high instantaneous current capability (HCC)	±30 Amps
transient intermodulation distortion (TIM)	0.08% (20Hz – 20kHz)
rise time	16 µsec
slew rate	40V/µsec

FM Tuner Specifications

frequency range	87.5–108MHz
usable sensitivity	1.5µV/14.8dBf
signal-to-noise ratio mono/stereo	73/70dB
distortion mono/stereo	0.3/0.5%
stereo separation	40dB @ 1kHz
selectivity	±400kHz, 60dB
image rejection	40dB
IF rejection	100dB
tuner output level	500mV @ 1kHz, ±75kHz Dev

AM Tuner Specifications

frequency range	520–1710kHz
signal-to-noise ratio	35dB
usable sensitivity	800µV/M
distortion	1kHz, 50% Mod 1.5%
selectivity	±10kHz, 30dB

Video Specifications

video format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response	10Hz–8MHz (–3dB)

General Specifications

power requirement	AC 120V/60Hz
power consumption	72W idle, 290W maximum (2 channels driven)
width	17.3 inches (440mm)
height	6.2 inches (156mm)
depth	14.7 inches (375mm)
weight	27.9 lb (12.6 kg)
