Source DVD HDMI 1 HDMI 2 HDMI 3 Video 1 Video 2 Aux 1 Aux 2 CD Tape Tuner TV
Title TUNER
Audio Input COAX 1 HDMI HDMI HDMI ANALOGUE OPTICAL 1 ANALOGUE ANALOGUE ANALOGUE ANALOGUE INT. TUNER OPTICAL 1
Auto Poll ON OFF OFF OFF OFF ON OFF OFF OFF ON – – OFF
Surround Mode
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
LOGIC 7
MOVIE
Table A2 – Source Setting Defaults
Device Type AVR Source Audio Connections Video Connections
Cable TV, Satellite, HDTV or other device that
delivers television programs
Video 1 Video 1 Analogue inputs •
Optical 1 Input (if not in use with HDMI 3 •
Composite Video 1 Input
VCR, DVR, PVR, or other audio/video recorder Video 2 Video 2 Analogue (inputs and outputs) •
Any one available coaxial or optical digital audio •
input with corresponding coax digital output
Composite Video 2 Input •
For recording, use Composite Video 2 Output •
DVD player, Blu-ray Disc player DVD or HDMI
(for Blu-ray Disc)
DVD Analogue Inputs •
Coax 1 Input •
DVD Component Video Input •
HDMI-capable disc player, game console or
other audio/video device
HDMI 1 HDMI 1 Input • HDMI 1 Input •
HDMI-capable disc player, game console or
other audio/video device
HDMI 2 HDMI 2 Input • HDMI 2 Input •
HDMI-capable disc player, game console or
other audio/video device
HDMI 3 HDMI 3 Input • HDMI 3 Input •
Portable audio device AUX 1 or AUX 2 AUX inputs on front and rear panels • Not required •
CD player CD CD Analogue Inputs •
Any one available coaxial or optical digital •
audio input
Not required •
CD-R, MiniDisc, cassette Tape Tape Analogue (inputs and outputs) •
Any one available coaxial or optical digital •
audio input
Use corresponding optical digital output •
Not required •
Note: The AVR is equipped with a total of three digital audio inputs. Certain digital audio connections are recommended simply because those digital audio inputs are assigned to those sources by
default at the factory. But any digital audio input may be reassigned to any source. Since you may not be using all of the AVR's sources, you may reassign a digital audio input that is recommended
for a source you aren’t using to another device. Table A1 is a guideline; you may need to make adjustments to fit your system.
Table A1 – Recommended Source Component Connections
Appendix – Default settings, worksheets, remote product codes
Appendix
