Harman Kardon AVR 158 User Manual

34
AVR 158
No. Button Name AVR Function DVD CD/CD-R Tape VCR (VID1) TiVo
®
(VID1)
DMC (VID 1/
HDMI 1/2/3)
CBL (VID2) SAT (VID2)
HDMI
1/2/3
38 6 6 6 6 6 6 6 6 6 6
39 7 7 7 7 7 7 7 7 7 7
40 8 8 8 8 8 8 8 8 8 8
41 Tun-M Tuner Mode Chapter+ or Zoom Repeat Zoom
42 9 9 9 9 9 9 9 9 9 9
43 0 0 0 0 0 0 0 0 0 0
44 Memory Memory Audio or Playlist Time
Source
(DMC250 only)
45 Tuning Up Tuning Up Next Chapter Track Direct Cancel PPV Cancel
46 Direct
Direct Tuner
Entry
Angle Random Play Angle FAV FAV Angle/FAV
47 Clear Clear Clear Clear Clear Clear Clear Bypass Next
48 Preset Up Preset Tune Up Slow Forward +10 Music Alt
49 Tuning Down Tuning Down Prev Chapter Track Increment
50 Tone Tone mode V-off
51 RDS RDS Disc Skip Disc Skip Skip Play Mode
52 Preset Down
Preset Tune
Down
Slow Rev
53 M1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1 Macro 1
54 M2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2 Macro 2
55 M3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3 Macro 3
56 M4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4 Macro 4
57 Night Night Mode Select Subtitle On/Off CDP Select Subtitle
58 Skip Down Skip – (DVD) Step – Skip – Scan – Thumbs Down Skip – Skip – (DVD) Skip – (DVD)
59 Skip Up Skip + (DVD) Step + Skip + Scan + Thumbs Up Skip + Skip + (DVD) Skip + (DVD)
60 Dim Dimmer Dimmer Dimmer
61 Rewind G
R. Search
(DVD)
R. Search R. Search Rewind Rewind R. Search R. Search
R. Search
(DVD)
R. Search
(DVD)
R. Search
62 Play B Play (DVD) Play Play R. Play/F. Play Play Play Play Play (DVD) Play (DVD) Play
63 FF H
F. Search
(DVD)
F. Search F. Search Fast Fwd Fast Fwd F. Search F. Search
F. Search
(DVD)
F. Search
(DVD)
F. Search
64 Record Record Record/Pause Record Record Record
65 Stop Stop (DVD) Stop Stop Stop Stop Stop Stop Stop (DVD) Stop (DVD) Stop
66 Pause Pause (DVD) Pause Pause Pause Pause Pause Pause (DVD) Pause (DVD) Pause
* NOTE: There is no button #14
Note: When any of the transport controls are pressed while the remote is in AVR or Video 2 mode, the remote will automatically switch to DVD mode, and the command will be applied
to the DVD player. If you then press a button native to the original mode, e.g., Volume Down for the AVR, the remote will revert to the original mode. See
Remote-Channel Control
Punch-Through , on page 22, for more information.
Table A10 – Remote Control Function List (cont.)
Appendix
0296CSK - HK (x65Series) AVR158-230 OM [HKP1992], WORK05.indd 34 30/06/11 14:00:07

Harman Kardon AVR 158 Specifications

General

Receiver type	-
Frequency range	10 - 130000 Hz
RMS rated power	360 W
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (20-20KHz@8 Ohm)	60 W
HDMI in	3
PC in (D-Sub)	No
Audio (L/R) in	7
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	0
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
AM band range	522 - 1620 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	30
Analog signal format system	PAL
Display	VFD
Color depth	12 bit
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II
Volume control	Digital
Digital sound processing	24 bit
Apple docking compatibility	Not supported
Sustainability certificates	RoHS
On Screen Display (OSD) languages	DEU, ENG
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	540 W
Cables included	AC

Weight and Dimensions

Depth	385 mm
Width	440 mm
Height	165 mm
Weight	9100 g
