T5CN5
(2) On Chip program memory and data memory
Product name On chip Flash ROM On chip RAM
T5CN5 512Kbyte 32Kbyte
(3) 16-bit timer : 10 channels
16-bit interval timer mode
16-bit event counter mode
16-bit PPG output
Input capture function
(4) Real time clock (RTC) : 1 channel
Clock (hour, minute and second)
Calendar (Month, week, date and leap year)
Time correction
or
30 seconds (by software)
Alarm (Alarm output)
Alarm interrupt
(5) Watchdog timer : 1 channel
26 cycles of binary counter
Watchdog timer out
(6) General-purpose serial interface : 3 channels
Either UART mode or synchronous mode can be selected (4byte FIFO equipped)
(7) Serial bus interface : 3 channels
Either I
2C bus mode or synchronous mode can be selected.
(8) CEC : 1 channel
Transmission and reception per
byte.
(9) Remote control signal preprocessor : 2 channels
Can receive up to 72bit data at a time
(10) 10-bit A/D converter : 12 channels
Start by an internal or external timer trigger
Fixed channel/scan mode
Single/repeat mode
AD monitoring 2ch
Conversion speed 1.15usec(@fsys = 40MHz)
(11) Interrupt source
Internal: 42 factors…The order of precedence can be set over 7 levels (except the watchdog
timer interrupt).
External: 8 factors…The order of precedence can be set over 7 levels.
(12) Input/ output ports
79 pins
