Harman Kardon AVR 1600

Preliminary Information ADV7604
Pr. 0 | Page 7 of 12
PIN DESCRIPTION
Pin Mnemonic Type Function
1A DGND Ground Ground
1B RXD_5V HDMI Input 5V detect pin for Port D in the HDMI interface.
1C PWRDNB Input Active low system power detect. If low, EDID can be powered from +5V
signal of HDMI port when connected to active equipment.
1D RXC_5V HDMI Input 5V detect pin for Port C in the HDMI interface.
1E DE Digital Video Output DE (data enable) is a signal that indicates active pixel data.
1F HS Digital Video Output HS is a horizontal synchronization output signal in the CP and HDMI processor.
1G P1 Digital Video Output Video pixel output port
1H P3 Digital Video Output Video pixel output port
1J DGND Ground Ground
1K P4 Digital Video Output Video pixel output port
1L P6 Digital Video Output Video pixel output port
1M P8 Digital Video Output Video pixel output port
1N P9 Digital Video Output Video pixel output port
1P P10 Digital Video Output Video pixel output port
1R P12 Digital Video Output Video pixel output port
1T P14 Digital Video Output Video pixel output port
1U P16 Digital Video Output Video pixel output port
1V DGND Ground Ground
2A RXD_2- HDMI Input Digital Input Channel 2 complement of Port D in the HDMI interface.
2B RXD_2+ HDMI Input Digital Input Channel 2 true of Port D in the HDMI interface.
2C TVDD Power Terminator supply voltage (3.3V)
2D RXB_5V HDMI Input 5V detect pin for Port B in the HDMI interface.
2E CEC Digital I/O Consumer electronic control channel
2F VS_FIELD Digital Video Output VS is a vertical synchronization output signal in the CP and HDMI
processor. FIELD is a field synchronization output signal in all interlaced
video modes. VS or FIELD can be configured for this pin.
2G P0 Digital Video Output Video pixel output port
2H P2 Digital Video Output Video pixel output port
2J DGND Ground Ground
2K P5 Digital Video Output Video pixel output port
2L P7 Digital Video Output Video pixel output port
2M DGND Ground Ground
2N DVDDIO Power Digital I/O supply voltage (3.3V)
2P P11 Digital Video Output Video pixel output port
2R P13 Digital Video Output Video pixel output port
2T P15 Digital Video Output Video pixel output port
2U P17 Digital Video Output Video pixel output port
2V P18 Digital Video Output Video pixel output port
3A RXD_1- HDMI Input Digital Input Channel 1 complement of Port D in the HDMI interface.
3B RXD_1+ HDMI Input Digital Input Channel 1 true of Port D in the HDMI interface.
3C TVDD Power Terminator supply voltage (3.3V)
3D RXA_5V HDMI Input 5V detect pin for Port A in the HDMI interface.
3F EP_MISO Digital Input SPI Master In/Slave Out for External EDID Interface
3G EP_CS Digital Output SPI Chip Select for External EDID Interface
3H RAW_VSYNC Analog Output This pin outputs the raw-sliced, embedded CSync or raw digital HS/CS.
3J MCLKOUT Misc Digital Audio master clock output.
3K LRCLK Misc Digital Data output clock for left and right audio channels.
3L I2S3 Misc Digital I
2
S Audio (Channel 7 and Channel 8).
3M DGND Ground Ground
3N DVDDIO Power Digital I/O supply voltage (3.3V)
AVR1600 harman/kardon
92
