Harman Kardon AVR 1600

ADV7604 Preliminary Information
Pr. 0 | Page 8 of 12
3P I2S0 Misc Digital I
2
S Audio (Channel 1 and Channel 2).
3R DGND Ground Ground
3T DGND Ground Ground
3U P19 Digital Video Output Video pixel output port
3V P20 Digital Video Output Video pixel output port
4A RXD_0- HDMI Input Digital Input Channel 0 complement of Port D in the HDMI interface.
4B RXD_0+ HDMI Input Digital Input Channel 0 true of Port D in the HDMI interface.
4C CVDD Power Comparator supply voltage (1.8V)
4D DDCD_SDA HDMI Input HDCP slave serial clock Port D. DDCD_SDA is a 3.3 V input that is 5 V tolerant.
4F EP_MOSI Digital Input SPI Master Out/SLAVE OUT for External EDID Interface
4G EP_SCK Digital Output SPI Clock for External EDID Interface
4H RAW_SYNC Analog Output This pin outputs the raw-sliced, embedded CSync or raw digital HS/CS.
4J SPDIF Misc Digital S/PDIF digital audio output.
4K SCLK Misc Digital Audio serial clock output.
4L I2S2 Misc Digital I
2
S Audio (Channel 5 and Channel 6).
4M DGND Ground Ground
4N DVDDIO Power Digital I/O supply voltage (3.3V)
4P I2S1 Misc Digital I
2
S Audio (Channel 3 and Channel 4).
4R DGND Ground Ground
4T DGND Ground Ground
4U P21 Digital Video Output Video pixel output port
4V P22 Digital Video Output Video pixel output port
5A RXD_C- HDMI Input Digital input clock complement of Port D in the HDMI interface.
5B RXD_C+ HDMI Input Digital input clock true of Port D in the HDMI interface.
5C DGND Ground Ground
5D DDCD_SCL HDMI Input HDCP slave serial clock Port D. DDCD_SCL is a 3.3 V input that is 5 V tolerant.
5R SCL Misc Digital I
2
C port serial clock input (maximum clock rate of 400 kHz). SCL is the
clock line for the control port.
5T P25 Digital Video Output Video pixel output port
5U P23 Digital Video Output Video pixel output port
5V P24 Digital Video Output Video pixel output port
6A DGND Ground Ground
6B TVDD Power Terminator supply voltage (3.3V)
6C TVDD Power Terminator supply voltage (3.3V)
6D DDCC_SDA HDMI Input HDCP slave serial clock Port C. DDCC_SDA is a 3.3 V input that is 5 V tolerant.
6R DVDDIO Power Digital I/O supply voltage (3.3V)
6T DVDDIO Power Digital I/O supply voltage (3.3V)
6U DGND Ground Ground
6V DGND Ground Ground
7A RXC_2- HDMI Input Digital Input Channel 2 complement of Port C in the HDMI interface.
7B RXC_2+ HDMI Input Digital Input Channel 2 true of Port C in the HDMI interface.
7C TVDD Power Terminator supply voltage (3.3V)
7D DDCC_SCL HDMI Input HDCP slave serial clock Port C. DDCC_SCL is a 3.3 V input that is 5 V tolerant.
7G DGND Ground Ground
7H DGND Ground Ground
7J DVDD Power Digital supply voltage (1.8 V).
7K DVDD Power Digital supply voltage (1.8 V).
7L DVDD Power Digital supply voltage (1.8 V).
7M DVDD Power Digital supply voltage (1.8 V).
7R INT1 Misc Digital Interrupt pin 1, can be active low or active high. When status bits change, this
pin is triggered. The events that trigger an interrupt are under user control.
7T SDA Misc Digital I
2
C port serial data input/output pin. SDA is the data line for the control port.
7U P26 Digital Video Output Video pixel output port
7V P27 Digital Video Output Video pixel output port
AVR1600 harman/kardon
93
