Preliminary Information ADV7604
Pr. 0 | Page 9 of 12
8A RXC_1- HDMI Input Digital Input Channel 1 complement of Port C in the HDMI interface.
8B RXC_1+ HDMI Input Digital Input Channel 1 true of Port C in the HDMI interface.
8C DGND Ground Ground
8D CVDD Power Comparator supply voltage (1.8V)
8G DGND Ground Ground
8H DGND Ground Ground
8J DGND Ground Ground
8K DVDD Power Digital supply voltage (1.8 V).
8L DVDD Power Digital supply voltage (1.8 V).
8M DVDD Power Digital supply voltage (1.8 V).
8R CLAMPIN External Clamp External clamp signal. This is an optional mode of operation for the ADV7604.
8T SYNC_OUT/INT2 Misc Digital Interrupt pin 2, can be active low or active high. When status bits change, this
pin is triggered. The events that trigger an interrupt are under user control.
8U DCLKIN External Clock and
Clamp
External clock for ADC sampling. This is an optional mode of operation for
the ADV7604.
8V LLC Digital Video Output Line locked output clock for the pixel data (range is 13.5 MHz to 170 MHz).
9A RXC_0- HDMI Input Digital Input Channel 0 complement of Port C in the HDMI interface.
9B RXC_0+ HDMI Input Digital Input Channel 0 true of Port C in the HDMI interface.
9C DGND Ground Ground
9D DGND Ground Ground
9G DGND Ground Ground
9H DGND Ground Ground
9J DGND Ground Ground
9K DGND Ground Ground
9L DGND Ground Ground
9M DGND Ground Ground
9R DVDDIO Power Digital I/O supply voltage (3.3V)
9T DVDDIO Power Digital I/O supply voltage (3.3V)
9U P28 Digital Video Output Video pixel output port
9V P29 Digital Video Output Video pixel output port
10A RXC_C- HDMI Input Digital input clock complement of Port C in the HDMI interface.
10B RXC_C+ HDMI Input Digital input clock true of Port C in the HDMI interface.
10C DGND Ground Ground
10D RTERM Misc Analog Sets internal termination resistance. A 500 Ω resistor between this pin and
GND should be used.
10G DGND Ground Ground
10H DGND Ground Ground
10J DGND Ground Ground
10K DGND Ground Ground
10L DGND Ground Ground
10M DGND Ground Ground
10R DGND Ground Ground
10T DGND Ground Ground
10U DGND Ground Ground
10V DGND Ground Ground
11A TVDD Power Terminator supply voltage (3.3V)
11B TVDD Power Terminator supply voltage (3.3V)
11C TVDD Power Terminator supply voltage (3.3V)
11D CVDD Power Comparator supply voltage (1.8V)
11G PVDD Power PLL supply voltage (1.8 V).
11H AGND Ground Ground
11J AGND Ground Ground
11K AGND Ground Ground
11L AGND Ground Ground
