T5CN5
2.3 Pin Names and Power Supply Pins
Table 2.4 Pin Names and Power Supplies
Pin name
Power
supply
PA DVCC
PB DVCC
PC AVCC
PD AVCC
PE DVCC
PF DVCC
PG DVCC
PH DVCC
PI DVCC
PJ DVCC
PK DVCC
X1, X2 CVCC
XT1, XT2 DVCC
RESET
DVCC
NMI
DVCC
MODE DVCC
2.4 Pin Numbers and Power Supply Pins
Table 2.5 Pin Numbers and Power Supplies
Power
supply
Pin number Voltage range
DVCC 14, 62
2.7V~3.6V
AVCC 5
REGVCC 76
CVCC 71
