Harman Kardon AVR 1600 - Page 42

Ref. Designator Part Number Qty
Description
MAIN PCB ASS'Y COP12170B
C809 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C810 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C904 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV 1 EA
C906 CCEA1EH102E CAP , ELECT 1000UF 25V 1 EA
C915 CCET50VKL4103NK CAP , ELECT 10000UF/50V 1 EA
C916 CCET50VKL4103NK CAP , ELECT 10000UF/50V 1 EA
Semiconductors
D501 HVD1SS133MT DIODE 1SS133T-77 1 EA
D502 HVD1SS133MT DIODE 1SS133T-77 1 EA
D503 HVD1SS133MT DIODE 1SS133T-77 1 EA
D504 HVD1SS133MT DIODE 1SS133T-77 1 EA
D505 HVD1SS133MT DIODE 1SS133T-77 1 EA
D581 HVD1SS133MT DIODE 1SS133T-77 1 EA
D582 HVD1SS133MT DIODE 1SS133T-77 1 EA
D583 HVD1SS133MT DIODE 1SS133T-77 1 EA
D584 HVD1SS133MT DIODE 1SS133T-77 1 EA
D585 HVD1SS133MT DIODE 1SS133T-77 1 EA
D801 HVD1SS133MT DIODE 1SS133T-77 1 EA
D802 HVD1SS133MT DIODE 1SS133T-77 1 EA
D803 HVD1SS133MT DIODE 1SS133T-77 1 EA
D804 HVD1SS133MT DIODE 1SS133T-77 1 EA
D901 HVD1N5819T DIODE , SCHOTTKY 1N5819 1 EA
D902 HVD1SS133MT DIODE 1SS133T-77 1 EA
D911 HVD1SS133MT DIODE 1SS133T-77 1 EA
D912 HVD1SS133MT DIODE 1SS133T-77 1 EA
D914 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
D917 HVD1SS133MT DIODE 1SS133T-77 1 EA
D953 HVD1SS133MT DIODE 1SS133T-77 1 EA
D954 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
D955 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
D956 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
D957 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
D961 HVD1N5819T DIODE , SCHOTTKY 1N5819 1 EA
D962 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
D963 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
D964 HVD1SS133MT DIODE 1SS133T-77 1 EA
D967 HVD1SS133MT DIODE 1SS133T-77 1 EA
D968 HVD1SS133MT DIODE 1SS133T-77 1 EA
D969 HVD1SS133MT DIODE 1SS133T-77 1 EA
D973 HVD1SS133MT DIODE 1SS133T-77 1 EA
D974 HVD1SS133MT DIODE 1SS133T-77 1 EA
D975 HVD1SS133MT DIODE 1SS133T-77 1 EA
D976 HVD1SS133MT DIODE 1SS133T-77 1 EA
D979 HVDMTZJ5.1BT DIODE , ZENER MTZJ5.1B 1/2W 1 EA
IC97 HVIRE5VT28CATZ I.C , RESET (RICOH) RE5VT28CATZ 1 EA
Q501 HVTKTA1268GRT TRANSISTOR PNP KTA1268GR 1 EA
Q502 HVTKTA1268GRT TRANSISTOR PNP KTA1268GR 1 EA
Q503 HVTKTA1268GRT TRANSISTOR PNP KTA1268GR 1 EA
Q504 HVTKTA1268GRT TRANSISTOR PNP KTA1268GR 1 EA
Q505 HVTKTA1268GRT TRANSISTOR PNP KTA1268GR 1 EA
Q511 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q512 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q513 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q514 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q515 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q516 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q517 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q518 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q519 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q520 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR 1 EA
Q541 HVTKTC3198YT TRANSISTOR NPN KTC3198Y 1 EA
Q542 HVTKTC3198YT TRANSISTOR NPN KTC3198Y 1 EA
Q543 HVTKTC3198YT TRANSISTOR NPN KTC3198Y 1 EA
