Harman Kardon AVR 1600 - Page 44

Ref. Designator Part Number Qty
Description
MAIN PCB ASS'Y COP12170B
Q804 CVT2SB1559P43M TR , POWER (DARLINGTON TYPE) PNP 2SB1559 (PNPMT-100PWR MICA 4
3
1EA
Q805 CVT2SD2389P43M TR , POWER (DARLINGTON TYPE) NPN 2SD2389 (NPNMT-100PWR MICA 4
3
1EA
Q807 CVT2SB1559P43M TR , POWER (DARLINGTON TYPE) PNP 2SB1559 (PNPMT-100PWR MICA 4
3
1EA
Q851 HVTKTD600KGR TRANSISTOR , BIAS NPN KTD600KGR 1 EA
Q852 HVTKTD600KGR TRANSISTOR , BIAS NPN KTD600KGR 1 EA
Q853 HVTKTD600KGR TRANSISTOR , BIAS NPN KTD600KGR 1 EA
Q854 HVTKTD600KGR TRANSISTOR , BIAS NPN KTD600KGR 1 EA
Q855 HVTKTD600KGR TRANSISTOR , BIAS NPN KTD600KGR 1 EA
Q856 HVTKTD600KGR TRANSISTOR , BIAS NPN KTD600KGR 1 EA
Q857 HVTKTD600KGR TRANSISTOR , BIAS NPN KTD600KGR 1 EA
IC95 HVIKIA78R05PI REGULATOR (5V OUTPUT LOW DROP) KIA78R05PI 1 EA
Q858 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1 EA
Q871 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1 EA
Q872 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1 EA
Q874 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1 EA
Q875 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1 EA
Q876 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1 EA
Q877 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1 EA
Q881 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1 EA
Q882 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1 EA
Q883 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1 EA
Q884 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1 EA
Q885 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1 EA
Q886 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1 EA
Q887 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1 EA
Resistors
R500 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R501 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1 EA
R502 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1 EA
R503 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1 EA
R504 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1 EA
R505 CRD20TJ433T RES , CARBON 43K OHM 1/5W J 1 EA
R506 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1 EA
R507 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1 EA
R508 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1 EA
R509 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1 EA
R510 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1 EA
R511 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R512 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R513 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R514 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R515 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R516 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R517 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R518 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R519 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R520 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R521 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1 EA
R522 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1 EA
R523 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1 EA
R524 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1 EA
R525 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1 EA
R531 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R532 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R533 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R534 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R535 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R536 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R537 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R538 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R539 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R540 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R541 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1 EA
