Harman Kardon AVR 1600

Ref. Designator Part Number Qty
Description
INPUT (DSP) PCB ASS'Y CUP12176C
C724 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C726 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C728 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C730 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C735 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C737 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C740 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C749 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C750 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C752 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C753 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C764 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C766 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C732 CCEA0JKR3222E CAP , ELECT 1EA
Semiconductors
D201 HVD1SS355T DIODE , CHIP 1EA
D202 HVD1SS355T DIODE , CHIP 1EA
D203 HVD1SS355T DIODE , CHIP 1EA
D204 HVD1SS355T DIODE , CHIP 1EA
D207 HVD1SS355T DIODE , CHIP 1EA
D208 HVD1SS355T DIODE , CHIP 1EA
D209 HVD1SS355T DIODE , CHIP 1EA
D210 HVD1SS355T DIODE , CHIP 1EA
D211 HVD1SS355T DIODE , CHIP 1EA
D212 HVD1SS355T DIODE , CHIP 1EA
D213 HVD1SS355T DIODE , CHIP 1EA
D214 HVD1SS355T DIODE , CHIP 1EA
D215 HVD1SS355T DIODE , CHIP 1EA
D216 HVD1SS355T DIODE , CHIP 1EA
IC20 CVINJW1197CFC2 I.C , VOL WITH INPUT SELECTOR NJW1197CFC2 1 EA
IC21 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC22 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC23 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC24 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC25 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC31 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC32 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC33 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC34 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC38 HVTKTC812TB TRANSISTOR , CHIP(TS6) KTC812T-B-RTK 1 EA
IC39 HVTKTC812TB TRANSISTOR , CHIP(TS6) KTC812T-B-RTK 1 EA
IC40 HVTKTC812TB TRANSISTOR , CHIP(TS6) KTC812T-B-RTK 1 EA
IC41 HVTKTC812TB TRANSISTOR , CHIP(TS6) KTC812T-B-RTK 1 EA
IC42 CVIKIA1117S18 I.C , REGULATOR(SOT-223) KIA1117S/F18, SOT-223 1 EA
IC43 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223 1 EA
IC44 CVIM12L16161A5TG I.C, 16MB SDRAM (ESMT) M12L16161A5TG 1 EA
IC45 HVTKTC812TB TRANSISTOR , CHIP(TS6) KTC812T-B-RTK 1 EA
IC46 CVIM24C32WMN6TP I.C , EEPROM (32 Kbit) ST M24C32WMN6TP 1 EA
IC47 CVIF25L008A50PAG I.C , 8Mbit SPI Serial FLASH (50MHz/8lead SOIC) F25L008A-50PAG 1 EA
IC48 CVIANAM1458AT I.C , U-COM (AVR1600) ANAM1458AT 1 EA
CVIT5CN5 I.C , U-COM (512KB/32KB, LQFP100P) TOSHIBA BLANK DO NOT USE 1 EA
IC49 CVITMP92FD28FG I.C , USB DECODER FLASH(100PIN, QFP) TOSHIBA TMP92FD28DFG, FLASH 1 EA
IC50 HVITC74HCU04AFN IC , INVERTER TC74HCU04AFN 1 EA
IC51 HVICS42528-CQ I.C , CODEC + DIR (CIRRUS LOGIC) CS42528-CQ 1 EA
IC52 HVINJM2391DL133 I.C , CHIP REGULATOR (+3.3V) JRC CS42528-CQ 1 EA
IC53 CVITC74VCX541FT I,C , OCTAL BUS BUFFER (TOSHIBA) NJM2391DL133 1 EA
IC54 HVITC74VHC157FT I.C , 2-CHANNEL MUX (TOSHIBA) TC74VHC157FT 1 EA
IC55 CVICS497024CVZ I.C , DSP (CIRRUS LOGIC) CS497024CVZ 1 EA
Q307 HVTKRA107S TRANSISTOR, CHIP KRA107S 1 EA
Q729 HVTKRC107S TRANSISTOR , CHIP KRC107S 1 EA
Q730 HVTKRC107S TRANSISTOR , CHIP KRC107S 1 EA
Q731 HVTKRA107S TRANSISTOR, CHIP KRA107S 1 EA
Q732 HVTKRA107S TRANSISTOR, CHIP KRA107S 1 EA
AVR1600 harman/kardon
58
