Harman Kardon AVR 1600

Ref. Designator Part Number Qty
Description
INPUT (DSP) PCB ASS'Y CUP12176C
R815 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R816 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R910 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R932 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R960 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R963 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R966 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
R992 CRJ10DJ562T RES , CHIP (5.6K OHM) 1608 SIZE 1 EA
Miscellaneous
CN15 CJP17GA193ZY WAFER, CARD CABLE (SMD) 1 EA
L701 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L702 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L703 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L704 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
L705 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
BN12 CJP27GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 27P) MOLEX 52045-**45 1 EA
BN72 CJP31GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 31P) MOLEX 52045-**45 1 EA
CN14 CJP15GA115ZY WAFER , CARD CABLE 1 EA
CN17 CJP06GB142ZB PIN HEADER(6P, 2.54mm) 1 EA
CN19 CJP07GA01ZY WAFER , STRAIGHT(7PIN) 1 EA
CN20 CJP07GI237ZW LOCKING TYPE , STRAIGHT WAFER, 2.5MM 1 EA
CN51 CJP07GA01ZY WAFER , STRAIGHT(7PIN) 1 EA
CN52 CJP03GA01ZY WAFER 1EA
JK11 CJJ4P014W JACK , IN/OUT 1EA
JK12 CJJ4R019W TERMINAL , IN/OUT 1EA
JK13 CJJ4R019W TERMINAL , IN/OUT 1EA
JK14 CJJ4R037W JACK , BOARD 1EA
JK43 CJJ2D008Z JACK , STEREO 1EA
JK78 CJJ4S022Z JACK , BOARD 1EA
L301 CLM4B001Z COIL , MPX (FM 19KHz FILTER) 1 EA
L302 CLM4B001Z COIL , MPX (FM 19KHz FILTER) 1 EA
X701 COX24576E180TF CRYSTAL , 24.576MHz CRYSTAL_HC-49/S_18PF 1 EA
X702 HOX10000E220TF CRYSTAL(HC-49/S,ATS) 10MHz CL-22P 1 EA
X703 COX09000E150C CRYSTAL(9MHZ) 1EA
X704 HOX00032K120I CRYSTAL , 32.768KHZ TUNING FORK 1 EA
HDMI PCB ASS'Y CUP12178C
Capacitors
CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z 1 EA
C801 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C802 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C803 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C804 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C805 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C806 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C807 CCUS1H510JA CAP , CHIP (51PF) (51PF) 1 EA
C808 CCUS1H510JA CAP , CHIP (51PF) (51PF) 1 EA
C809 CCUS1H102KC CAP , CHIP 1000PF 50V K 1 EA
C810 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C811 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C812 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C813 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C814 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C815 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C816 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C817 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C818 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C819 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C820 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C821 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C822 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
AVR1600 harman/kardon
64
