Harman Kardon AVR 1600

Ref. Designator Part Number Qty
Description
HDMI PCB ASS'Y CUP12178C
C889 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C890 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C891 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C892 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C893 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C894 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C895 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C896 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C897 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C898 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C899 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C900 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C901 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C902 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C903 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C904 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C905 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C907 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C908 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C909 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C910 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C911 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C912 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C913 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C914 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C915 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C916 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C917 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C918 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C919 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C920 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C921 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C922 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
Semiconductors
D901 HVD1SR159-200 DIODE , RECTIFIER 1EA
D902 HVD1SR159-200 DIODE , RECTIFIER 1EA
D903 HVD1SR159-200 DIODE , RECTIFIER 1EA
D904 HVD1SR159-200 DIODE , RECTIFIER 1EA
IC101 CVIADV7604 IC , HDMI RX (BALL, BGA-260P) ANALOG DEVICE ADV7604 1 EA
IC102 CVIADV7510 I.C , HDMI 1.3 TX(100P LPFQ) ANALOG DEVICE ADV7510 1 EA
IC103 HVITC74HC4094FN I.C 8-BIT SHIFT AND STORE REGISTER (3-STATE) TC74HC4094AFN 1 EA
IC104 CVIKIA1117S50 I.C , REGULATOR(SOT-223) KIA1117S50-RTK/P 1 EA
IC105 HVIKIA7809AF I.C , REGULATOR KIA7809AF 1 EA
IC106 CVINJM2845DL118 IC, JRC LOW DROPOUT VOLTAGE REGULATOR NJM2845 1 EA
IC107 CVITC74VCX541FT I,C , OCTAL BUS BUFFER (TOSHIBA) TC74VCX541FT 1 EA
IC108 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223 1 EA
IC109 CVIKIA1117S18 I.C , REGULATOR(SOT-223) KIA1117S/F18, SOT-223 1 EA
IC110 CVINJM2845DL118 IC, JRC LOW DROPOUT VOLTAGE REGULATOR NJM2845 1 EA
Q801 HVTKRA102S TRANSISTOR , CHIP KRA102S 1 EA
Q802 HVTKRA102S TRANSISTOR , CHIP KRA102S 1 EA
Q803 CVTKRC103S TRANSISTOR , CHIP KRC103S 1 EA
Q804 CVTKRC103S TRANSISTOR , CHIP KRC103S 1 EA
Q806 CVTKRC103S TRANSISTOR , CHIP KRC103S 1 EA
Q807 HVTKRA102S TRANSISTOR , CHIP KRA102S 1 EA
Q808 CVTKRC103S TRANSISTOR , CHIP KRC103S 1 EA
Resistors
RN100 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN101 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN102 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN103 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN104 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
AVR1600 harman/kardon
66
